CHART IN THE BOX

• VISCOMAT DC PUMP
• INSTRUCTION MANUAL

DETAILS

ON/OFF SWITCH GEAR ROTOR
TYPE OF FLUID OIL SAE 80W90
TEMPERATURE 24 °C
DIMENSIONS
223 110

MATERIALS
• BODY: CAST IRON
VISCOMAT DC 60/2 • GEARS: SINTERED STEEL
261 100 • SHAFT: STEEL
• BYPASS: BRASS
34.5 33 52.5 70

VISCOMAT DC 60/1
157.5

34

38.5 52.5 70
Dimensions expressed in millimeters
TECHNICAL DATA
FLOW RATE WORKING VOLTAGE INLET
PRESSURE
CODE DESCRIPTION FLUIDS TYPE RPM OUTLET PRESSURE
SWITCH
L/MIN GPM BAR PSI MOTOR POWER AMP. BSP
V./ HZ WATT MAX.
F0030902A VISCOMAT 60/1 12V DC O 4 1,2 5 70 12 150 18,5 2900 1/2” BSP NO
F0030901A VISCOMAT 60/2 12V DC (*) O 10 2,8 4 57 12 300 35 2900 3/4” BSP NO
F0030900A VISCOMAT 120/1 12V DC O 5 1,4 10 140 12 200 26,5 2900 1/2” BSP NO
F0031002A VISCOMAT 60/1 24V DC O 4 1,2 5 70 24 150 9,5 2900 1/2” BSP NO
F0031001A VISCOMAT 60/2 24V DC (*) O 10 2,8 4 57 24 300 18 2900 3/4” BSP NO
F0031000A VISCOMAT 120/1 24V DC O 5 1,4 10 140 24 200 19,5 2900 1/2” BSP NO
F00311000 VISCOMAT 120/1 12V PST O 5 1,4 10 140 12 200 22,5 2900 1/2” BSP YES
F00311010 VISCOMAT 120/1 24V PST O 5 1,4 10 140 24 200 19,5 2900 1/2” BSP YES
(*) FOR VISCOMAT DC 60/2 MAX OIL VISCOSITY 600 CST - (**) MEASURING MADE WITH PUMP
ASSEMBLED OVER DRUM TAKEN FROM 1 METER DISTANCE WITHOUT ANY ENVIROMENTAL NOISES. VISCOMAT DC

ELECTRIC PUMPS 39
