P. 37
FILTRATION FLUID TANK HOSE REELS ACCESSORIES MERCHANDISE
MONITORING MONITORING
INDEX
A A Ad B D F G R G K O W W S
AIR ANTIFREEZE AdBlue® BIODIESEL DIESEL FOOD GASOLINE GREASE KEROSENE OIL WATER WINDSCREEN
CHART IN THE BOX
• VISCOMAT GEAR PUMP
• ANTI-SIPHON KIT
• KIT FLOWMAT
• INSTRUCTION MANUAL
DETAILS
ON/OFF SWITCH ADJUSTABLE BYPASS
TYPE OF FLUID OIL SAE 10W40
TEMPERATURE 20 °C
DIMENSIONS
PRESSURE SWITCH
MATERIALS
• BODY: CAST IRON
• GEARS: SINTERED STEEL
• SHAFT: STEEL
• BYPASS: BRASS
170
355 210
Dimensions expressed in millimeters
TECHNICAL DATA
WORKING
FLOW RATE PRESSURE VOLTAGE INLET
CODE DESCRIPTION FLUIDS TYPE RPM OUTLET BYPASS
VALVE
L/MIN GPM BAR PSI MOTOR POWER AMP. BSP
MAX.
WATT
V./ HZ
F0030200D VISCO FLOWMAT 200/2 O 9 2,4 12 170 230-50/60 800 3,8 1450 1” BSP YES
F0030204D VISCO FLOWMAT 230/3 O 14 3,7 16 227 230-50/60 1200 6 1450 1” BSP YES
F0030206D VISCO FLOWMAT 350/2 O 9 2,4 25 355 230-50/60 1250 6 1450 1” BSP YES
*MEASURING MADE WITH PUMP ASSEMBLED OVER DRUM TAKEN FROM 1 METER DISTANCE
WITHOUT ANY ENVIROMENTAL NOISES. VISCOFLOWMAT
ELECTRIC PUMPS 37
