07 High pressure hoses & hose fittings

Hose bend restrictor
Hose bend restrictor - plastic Cartridge for plugs Hose protection

K
For plugs placed at the gun PVC
Black R+M Nr. R+M Nr.
R+M Nr. 316 960 6 6 308 491 620 per metre 20 mm 16 mm
308 52 13.5 mm 316 960 8 8 308 491 621 roll at 20 m 20 mm 16 mm
Hose bend restrictor - plastic / spiral

Spiral black Spiral blue Spiral red
R+M Nr. R+M Nr. R+M Nr.
308 55 13.2 mm 308 551 13.2 mm 308 552 13.2 mm

Packing units
Hose bend restrictor - plastic 500 pieces
Hose bend restrictor - plastic / spiral 400 pieces

Hose bend restrictor in wave design - showing your company logo!
We offer you the possibility to combine your personal spray
guns ST-2300 and ST-2600 with your individual hose bend 72
restrictor, this is possible from 525 pieces. You are invited to
choose your favourite colour of your hose bend restrictor and to
think about what you would like to have written on it or which 12
logo you would like to see on it. It is really up to you as you can
give free rein to your creativity! The lettering on the two fields is
solely determined by you. By means of labelling your personal
145
hose bend restrictor you succeed in enhancing the product itself
and also in making your company and brand better known.
The hose bend restrictor very bendable and also flexible at low 0 35,4 D1 D2 0 32
temperature is equipped with a lip that engages behind the
crimp cartridge and avoids any loosening. It is characterized by
a very smooth surface structure, oil and abrasion resistance.
colour colour-number nominal diameter D1 D2
The black and yellow versions are recommended to be used for red 1040 DN 8 14.6 21.7
outdoor applications. The blue and grey hose bend restrictor is
DN 10 14.6 23.0
especially designed for being used inside as for example in the
DN 12 21.0 26.6
food industry. It is generally phthalate-free, resistant to chemi- DN 12 * 21.0 26.5
cals as well as chlorine- and grease resistant in all colours.
black 660 DN 8 14.6 21.7
DN 10 14.6 23.0
DN 12 21.0 26.6
DN 12 * 21.0 26.5
blue 1010 DN 8 14.6 21.7
DN 10 14.6 23.0
DN 12 21.0 26.6
DN 12 * 21.0 26.5
grey 1020 DN 8 14.6 21.7
DN 10 14.6 23.0
DN 12 21.0 26.6
DN 12 * 21.0 26.5
yellow 1030 DN 8 14.6 21.7
DN 10 14.6 23.0
DN 12 21.0 26.6
DN 12 * 21.0 26.5
* hose bend restrictor for blufood
Symbols nominal diameter thread packing unit diameter
