TIG WELDING TECHNICAL
INFORMATION

WELDING CURRENT (A) TIG TIG FEATURES OTHER FEATURES AQUA DISPLAY WEIGHT
DUTY Ø MAX
CYCLE electrode
AC DC 50 100 150 200 250 300 350 EASY PULSE THIN SPOT
EN60974-1 (mm) PULSE MV-PFC VERSION (kg)
HF LIFT VRD JOB AQUA
INFINITY TIG 225 200A 200@25% 4 6
DC-HF/LIFT VRD 230V
TECNICA 190 TIG 170A
230V 160@20% 4 4,3
DC-LIFT VRD
120A
ADVANCE 227 XT 100V-120V 150@30% 4 7,4
MV/PFC VRD 200V-240V 200A 200@30%
1ph
TECHNOLOGY TIG 230 220A
230V 220@30% 4 9,7
DC-HF/LIFT VRD
TECHNOLOGY TIG 182 180A
230V 180@20% 4 11,3
AC/DC-HF/LIFT VRD
TECHNOLOGY TIG 222 200A
230V 200@24% 4 11,3
AC/DC-HF/LIFT VRD
SUPERIOR TIG 251 250A 230@20% 5 11,3
DC-HF/LIFT VRD 400V - 3 ph
SUPERIOR TIG 252 250A 230@20% 5 14,5
AC/DC-HF/LIFT VRD 400V - 3 ph
300A
SUPERIOR TIG 311 400V - 3 ph 250A 300@30% 5 13,2
3ph DC-HF/LIFT VRD 230V - 1 ph 200@42%
SUPERIOR TIG 322 270A 270@40% 5 26
AC/DC-HF/LIFT 400V - 3 ph
SUPERIOR TIG 421 350A
400V - 3 ph 350@35% 5 26
DC-HF/LIFT
SUPERIOR TIG 422 350A
400V - 3 ph 350@35% 5 31
AC/DC-HF/LIFT
CURRENT @ 60% - EN 60974-1

36
