STAINLESS STEEL HOSE REELS

Dimensions (mm) / Dimensioni (mm)
OPTIONAL + 60° Pos. A Pos. B Pos. C
180 -
150
180
150 12
12
413 447 200 150 205 150

250 120
460 192 Standard supply
605
Fornitura di serie

Hose reels model VX without hose / Avvolgitubo modello VX senza tubo
Fluid Max. pressure Code Inlet (Bsp) Outlet (Bsp) Capacity Weight (kg) ATEX
Fluido Pressione max. Codice Entrata (Gas) Uscita (Gas) Capacità Peso (kg) (optional)

(1/2”) 15 m/50 ft
Water/Acqua 100°C 60 bar/870 psi VX601215ST 1/2” M 1/2” M 14,5 •
(5/8”) 10 m/32 ft
Water/Acqua 150°C 400 bar/5800 psi VX4H3815ST 3/8” F 3/8” M 15 m/50 ft 14,5 •

Hose reels model VX with hose / Avvolgitubo modello VX completi di tubo

Fluid Pressure - Hose Code Inlet (Bsp) Outlet (Bsp) Hose diam. Hose length Weight (kg) Inlet hose ATEX
Fluido Pressione - Tubo Codice Entrata (Gas) Uscita (Gas) Tubo diam. Lungh. Tubo Peso (kg) Tubo entrata (optional)

VX101310K 1/2” M 1/2” M 13 x 20 10 m/32 ft 17 TC13005K
10 bar/145 psi (70°C)
Water 20 bar/290 psi (25°C)
Acqua 70°C Blue Thermoplastic VX101315K 1/2” M 1/2” M 13 x 20 15 m/50 ft 19 TC13005K
VX101610K 1/2” M 1/2” M 16 x 23 10 m/32 ft 18 TC16005K

10 bar/145 psi (90°C) VX101310KR 1/2” M 1/2” M 13 x 21 10 m/32 ft 17 TC1301KR
Water 20 bar/290 psi (25°C)
Blue Rubber/Gomma
Acqua 90°C
VX101315KR 1/2” M 1/2” M 13 x 21 15 m/50 ft 19 TC1301KR
250 bar/3625 psi VX2H3815 3/8” F 3/8” M 3/8” M 15 m/50 ft 21 TC38005H
1SC Hydro blue

VX4H3810 3/8” F 3/8” M 3/8” 10 m/32 ft 19 TC38005H
Water
Acqua 150°C VX4H3815 3/8” F 3/8” M 3/8” 15 m/50 ft 21 TC38005H •
400 bar/5800 psi
2SC Hydro blue
VX4H5115 3/8” F 3/8” M 5/16” 15 m/50 ft 20 TC38005H •
*VX4H3815X 3/8” F 3/8” F 3/8” 15 m/50 ft 21 T3801HX
* Hose with stainless steel fittings / Tubo con raccordi in acciaio inox
