UNLOADER SPINDLES & BYPASS SYSTEMS

Unloader spindle complete Easy start plunger kit

Fig. 44209 Fig. 445321 Fig. 141101
Design Order No. Order No.
for quadro big, therm devices until year of construction 43444 490411
2008, WS-Series, Profi-Jet-Series
for quadro 800 434441
for therm-1-Series 44209
for therm C/CA-Series, K2000-Series, Profi-Series, 40490
quadro small, quadro medium
for K 1150 T, K 1151 T, K 1152 TST 445321

for ULH 250 141322
for ULH 250 F 141328

for S250, UL 100 141101
for therm RP-Series 486032

for X A15, X A17 496026

CIRCUIT BOARDS

Delayed TS shut-down PCB therm-series PCB

Fig. 42564 Fig. 44952
■ Switch-off delay
■ suitable for quadro-Series ■ suitable for therm-Series Order No.
Design Order No. therm CA 44952
230 V 50 / 60Hz 42564 therm-1, therm RP 44359
400 V 50 / 60 Hz 42563 therm C, therm 1017 / 715 44836

PCB for Remote Control Kits Over temperature safety cut-out PCB

■ for cable up to 50m Length ■ suitable for therm-1-Series, 400 V 50 / 60 Hz
■ Switching of 4 functions
■ 400 V 50 / 60 Hz
Order No.
Order No.
44370
41377
