REMOTE CONTROL KITS

Remote control set with 4 functions Remote control set with 2 functions

Fig. 422401
■ Remote control set therm with 4 illuminated switches and emergency stop ■ Remote control set therm with 2 illuminated switches and emergency stop
■ incl. control unit, service plug and connection cable ■ incl. control unit, service plug and connection cable
■ Switching functions : ■ Switching functions :
Device On / Off Device On / Off
Heating On / Off Heating On / Off
Cleaning agent 1 On / Off Emergency stop
Cleaning agent 2 On / Off
Emergency stop Cable length m 25 50
Cable length m 25 50 Order No. 422401 422402
Order No. 422411 422412

Remote control set with 1 Function Cleaning agent pump

Abb. 42241111
Fromb . 4 22 4

■ for all stationary cold water units, all therm-1, all electrically ■ Delivery rate: 0.4 - 4.0 l/h
heated therm, all stationary therm ■ variable-speed
■ ON/OFF - Switch with Cable (2 x 1.5 mm²) up to max. 10 m ■ electronic connection: 230 V
■ Connection to the board
Order No. Order No.

41391 150387

Peristaltic tube

■ suitable for cleaning agent pump Order No. 150387

Order No.
150389
SWIVEL ARMS

Swivel arm

■ Galvanized steel | Boom with hose reel ST 14 stainless steel | Hose capacity outside | Supplied without high pressure hose
■ max. 300 bar | Inlet 3/8" male | Outlet 3/8" female
Length mm Weight Rotation Order No.
3570 50 180° 41382
4570 54 180° 41386

41
