CHART IN THE BOX

• MA 130 PUMP
• INSTRUCTION MANUAL
Q (U.S. g.p.m.)

0 1,3 2,6 3,9 5,2 6,6 7,9 9,2 10,5 11,8 13,2
80 262,4
70 150 300 229,6
7
60 196,8
6
50 420 164,0
5
40 131,2
4
30 3 98,4 DETAILS
HEAD (m) 20 2 65,6 H (ft)

10
32,8
0
0 5 10 15 20 25 30 35 40 45 50 0
FLOW RATE (litres/min) HEAVY DUTY MATERIALS TECHNOPOLYMER BODY

DIMENSIONS

247 100 EASY TO FIT
MATERIALS
• BODY: TECHNOPOLYMER
• FITTINGS: ALLUMINIUM
• DIAPHRAGMS: TECHNOPOLYMER

241

168 Ø 153

Dimensions expressed in millimeters

TECHNICAL DATA
FLOW INTAKE / AIR MAX SELF-PRI- MAX MAX AIR SUP- MAX Ø OF
CODE DESCRIPTION FLUIDS PUMP BODY IN / OUT RATE MEMBRANE DIAPHRAGM BALLS BALL SEATS* O-RING* DELIVERY CON- MING CAPACITY HEAD** PLY PRESSURE PASSING SOLID
TYPE
TYPE
L/MIN CONNECTION NECTION M M BAR MM
F00208A00 PIUSI MA 130 O D ALLUMINIUM 1/2” G 50 SINGLE NBR NBR ALLUMINIUM NBR G 1/2” F G 3/8” F 5 70 7 4
(*) ON REQUEST WE CAN PROVIDE MEMBRANES, BALLS, BALL SEATS AND O-RINGS IN DIFFERENT MATERIALS.
(**) THE VALUE DEPENDS ON THE CONFIGURATION OF THE PUMP MA 130

PNEUMATIC DIAPHRAGM PUMPS 47
