CHART IN THE BOX

• MA 140 PUMP
• INSTRUCTION MANUAL
Q (U.S. g.p.m.)

0 2,6 5,2 7,9 10,5 13,2 15,8 18,4 21,1 23,7 26,4
80 262,4
70 250 450 229,6
7
60 196,8
6
50 164,0
5 900
40 131,2
4
30 3 98,4 DETAILS
HEAD (m) 20 2 65,6 H (ft)

32,8
10
0
0 10 20 30 40 50 60 70 80 90 100 0
FLOW RATE (litres/min) HEAVY DUTY MATERIALS TECHNOPOLYMER BODY

DIMENSIONS

308 115 STURDY DESIGN
MATERIALS
• BODY: TECHNOPOLYMER
• FITTINGS: ALLUMINIUM
• DIAPHRAGMS: TECHNOPOLYMER

274

213 Ø 170

Dimensions expressed in millimeters

TECHNICAL DATA
FLOW INTAKE / AIR MAX SELF-PRI- MAX MAX AIR SUP- MAX Ø OF
CODE DESCRIPTION FLUIDS PUMP BODY IN / OUT RATE MEMBRANE DIAPHRAGM BALLS BALL SEATS* O-RING* DELIVERY CON- MING CAPACITY HEAD** PLY PRESSURE PASSING SOLID
TYPE
TYPE
L/MIN CONNECTION NECTION M M BAR MM
F00208P10 PIUSI MA 140 O D POLYPROPYLENE 1” G 100 SINGLE NBR NBR POLYPROPYLENE NBR G 1” F G 3/8” F 6 70 7 4
(*) ON REQUEST WE CAN PROVIDE MEMBRANES, BALLS, BALL SEATS AND O-RINGS IN DIFFERENT MATERIALS.
(**) THE VALUE DEPENDS ON THE CONFIGURATION OF THE PUMP MA 140

PNEUMATIC DIAPHRAGM PUMPS 49
