08 Sewer cleaning & sewer cleaning nozzles

Sewer cleaning hose assemblies
with nozzle without nozzle with nozzle no nozzle
Male M thread + M thread + QSC : m +
QSC
thread O-ring O-ring O-ring
M22 : 1/8" 1/8" : 1/8" M22 : 1/8"

Kr Kr
Plastic hoses with single fabric braid
R+M Nr. R+M Nr. R+M Nr.
Polya 5 200 bar 20 °C 8 m 412 012 008 412 010 008 412 040 008 Hoses with single wire braid and smooth cover
10 m 412 012 010 412 010 010 412 040 010 R+M Nr. R+M Nr.
15 m 412 012 015 412 010 015 412 040 015 Flexy 6 300 bar 100 °C 10 m 420 302 321 0 420 300 321 0
20 m 412 012 020 412 010 020 412 040 020 15 m 420 302 321 5 420 300 321 5
25 m 412 012 025 412 010 025 412 040 025 20 m 420 302 322 0 420 300 322 0
30 m 412 012 030 412 010 030 412 040 030 25 m 420 302 322 5 420 300 322 5
40 m 412 012 040 412 010 040 412 040 040 30 m 420 302 323 0 420 300 323 0

High pressure hoses with smooth cover - 500 bar
without nozzle
Fittings stainless steel
M thread :
QSC : Male thread
M thread
M22 : 1/8" M22 : 1/4" 1/4" : 1/4"

Hoses with double wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr.
Flexy 6 500 bar 150 °C 10 m 424 300 010 9 424 301 010 9 424 344 010 9
15 m 424 300 015 9 424 301 015 9 424 344 015 9
20 m 424 300 020 9 424 301 020 9 424 344 020 9

Sewer cleaning hose assemblies with mini-nozzle
Heat exchangers in thermal power stations or conveyor pipes in the food
industry are often sewers of 10 to 12 mm in diameter. In order to clean them
effectively from the inside a device for sewer cleaning with small diameters
and high pressures is required.
We have also in this case the best possible solution for you!
"small" as desired and "powerful" with great performance.
R+M Nr.
495 334 000 5 2 03 350 - 500 bar 60 °C 0.5 m We are talking about the new mini-device for sewer cleaning. Being only
495 334 002 0 2 03 350 - 500 bar 60 °C 2.0 m 9 mm in diameter the nozzle withstands the working pressure of up to 500
495 334 005 0 2 03 350 - 500 bar 60 °C 5.0 m bar. Completely sensational or what do you think? The nozzle for sewer
495 334 008 0 2 03 350 - 500 bar 60 °C 8.0 m cleaning is made out of stainless steel and equipped with three jet outlets
495 334 010 0 2 03 350 - 500 bar 60 °C 10.0 m to the back and one forward.
495 334 015 5 2 03 350 - 500 bar 60 °C 15.5 m The mini-nozzle for sewer cleaning is supplied with a black plastic hose
495 334 020 2 03 350 - 500 bar 60 °C 20.0 m with a nominal diameter of 2 and assembled with 1/8" M. The device is so
495 334 025 2 03 350 - 500 bar 60 °C 25.0 m suitable for all common high pressure cleaner.
