Page 183 - RM_2022

08 Sewer cleaning & sewer cleaning nozzles

ST-71 hose reel with sewer cleaning hose
The ST-71 hose reel is equipped with a 15 m Flexy sewer cleaning
hose DN 6. The frame of the reel is made out of stainless steel and
the reel is made out of plastic.
The space-saving and orderly solution can either be hung up at the
wall or refitted in high pressure cleaner.
The hose can be used as extension of high pressure hoses or as
sewer cleaning hose.
Max. 300 bar / 100 °C

R+M Nr.
200 071 615 1/4" M M22 M
200 071 620 1/8" M M22 M
200 071 625 M22 F M22 M
200 071 626 M22 F swivel M22 M

ST-540 foot valves

Incl. HP-gun ST-2605. Material housing powder- Incl. HP-gun ST-2750. Material housing powder- Incl. HP-gun ST-2750. Material housing powder-
coated steel. coated steel. coated steel.
Rubber feet. Rubber feet. Rubber feet.
Max. 350 bar / 45 l/min / 150 °C Max. 500 bar / 30 l/min / 150 °C Max. 500 bar / 30 l/min / 150 °C

R+M Nr. R+M Nr. R+M Nr.
200 540 500 1/4" M 3/8" F 200 540 550 1/4" M 3/8" F 200 540 560 M22 M M22 M

ST-33 high Pressure Filter Crimp nipples
Stainless steel. Flat sealing
R+M Nr.
315 393 8 1/4"
315 593 8 3/8"
315 693 10 3/8"
315 663 12 1/2"
Reduction nipple

Stainless steel. 500 bar
Brass with stainless steel filter. Bidirectional.
Max. 400 bar / 40 l/min. / 150 °C
R+M Nr. R+M Nr.
200 033 855 45.6 mm 1/4" M 1/4"F 040 002 207 1/4" F 1/8" M

Protective clothing is shown on the pages 537-538.

Symbols nozzle nominal diameter outlet inlet diameter thread height
