08 Sewer cleaning & sewer cleaning nozzles

ST-49 nozzles for sewer cleaning
Sewer cleaning nozzles with female thread
Hydro Mole
With its 3 very strong concentrated forward jets the Hydro Mole will tear Nozzle drilling as stepped bore for best protection against mechanical
through almost any kind of blockage. impact.
Front jets to blast thru roots and scale or for de-icing. Made of wear-resistant, hardened stainless steel.

Outside 22 mm. Outside 22 mm. Outside 25 mm.
Hardened stainless steel. Hardened stainless steel. Hardened stainless steel.
Max. 500 bar / 35 l/min. Max. 500 bar / 32 l/min. Max. 500 bar / 32 l/min.
R+M Nr. R+M Nr. R+M Nr.
120 460 385 1/4" F 070 120 163 392 1/4" F 065 120 163 393 3/8" F 065
Grease ball Root rat

rear jets for extreme thrust and highest wall coverage of the pipe. Desi- Equipped with rear jets for maximum thrust and 3 additional nozzles
gned for the ability to clean grease off the sidewall of pipes but has proven (45°) right behind its nose for better cleaning results and wall coverage the
to be great on root chokes, too. Completely spherical shape. nozzle has proven to be ideal on root chokes.
Nozzle drilling as stepped bore for best protection against mechanical Hardened stainless steel.
impact. Max. 500 bar / 30 l/min
Hardened stainless steel.
Max. 500 bar
R+M Nr. R+M Nr.
120 000 860 1/4" F 080 8 (0,6 mm) 120 155 672 1/4" F 060 3 (30°)

Mini-nozzles for sewer cleaning
Heat exchangers in thermal power stations or conveyor pipes in the food Being only 9.8 mm in diameter the nozzle withstands the working pressure
industry are often sewers of 10 to 12 mm in diameter. In order to clean of up to 500 bar.
them effectively from the inside a device for sewer cleaning with small Together with our R+M 1 / Bronze hose (30420) the complete sewer
diameters and high pressures is required. cleaning unit will be rated up to 300 bar and 100° C

Crimp nipple. M7 F. rear jets for maximum thrust and power- M7 F. rear jets for maximum thrust. Additional
DN 4. ful cleaning impact. 3 side jets (90°) for powerful cleaning impact and
M7 M. Outside 9.8 mm. optimal wall coverage.
Stainless steel. Stainless steel. Outside 9.8 mm. Stainless steel.
Max. 500 bar Max. 500 bar Max. 500 bar
R+M Nr. R+M Nr. R+M Nr.
040 001 946 22 120 000 380 030 3 120 373 373 065 3
120 001 380 065 3
