08 Sewer cleaning & sewer cleaning nozzles

ST-49 Ball type nozzle, 30°
Made out of wear-resistant, hardened stainless steel provided with front efficiency is considerably higher compared with those nozzles with drilled
jet insert or blind plug (interchangeable). Angle of jet is 30°, sturdy wall holes and the service life is several times longer.
thickness, long service life and a minimum of wear and tear. All nozzles Max. 500 bar
are provided with hardened stainless steel inserts. Due to this feature the
Applications:
» Suitable for removal of sludge
deposits
» Desilting of pipes
» Opening of frozen pipelines

30° 30° 30°
1/4" F. 3/8" F. 3/8" F.
Outside 25 mm. Outside 30 mm. Outside 30 mm.
rear jets, with front jet rear jets, with front jet rear jets, with front jet
R+M Nr. R+M Nr. R+M Nr.
649 030 216 060 060 6 649 030 314 060 060 4 649 030 316 060 060 6
649 030 216 080 080 6 649 030 314 080 080 4 649 030 316 080 080 6
649 030 216 100 100 6 649 030 314 100 100 4 649 030 316 100 100 6
649 030 216 120 120 6 649 030 314 120 120 4 649 030 316 120 120 6
30° 649 030 216 150 150 6 649 030 314 150 150 4 649 030 316 150 150 6
649 030 216 200 200 6 649 030 314 200 200 4 649 030 316 200 200 6

30° 30° 30° 30°
1/2" M. MR cone. 1/2" F. 3/4" F. 1" F.
Outside 30 mm. Outside 30 mm. Outside 38 mm. Outside 48 mm.
rear jets, with front jet rear jets, with front jet rear jets, with front jet rear jets, with front jet
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
649 040 416 060 060 6 649 030 416 060 060 6 649 030 516 100 100 6 649 030 618 120 120 8
649 040 416 080 080 6 649 030 416 080 080 6 649 030 516 120 120 6 649 030 618 150 150 8
649 040 416 100 100 6 649 030 416 100 100 6 649 030 516 150 150 6 649 030 618 170 170 8
649 040 416 120 120 6 649 030 416 120 120 6 649 030 516 170 170 6 649 030 618 210 210 8
649 040 416 150 150 6 649 030 416 150 150 6 649 030 516 200 200 6 649 030 618 260 260 8
649 040 416 200 200 6 649 030 416 200 200 6 649 030 516 250 250 6 649 030 618 315 315 8
649 030 416 315 315 6 649 030 618 390 390 8

new new

K K
30° 30°
M22x1.5 M. TR22 M**.
Outside 25 mm. Outside 25 mm.
rear jets rear jets
R+M Nr. R+M Nr.
120 000 833* 090 6 120 000 832 090 6

** thread coated with microencapsulated thread locking fluid
* stainless steel
Symbols nozzle diameter rear jets
