Sewer cleaning & sewer cleaning nozzles 08

Small plough jet nozzle
For 2 fan jets 1/4" M NPT For 2 ST-357 rotating nozzles

45°
<45°
360°

Fitted with two rear facing fan jets the small plough jet nozzle is great for Fitted with two rear facing ST-357 rotating nozzles the small plough jet
desilting drains and sewers. The heavy forged brass construction keeps the nozzle is the ideal solution for desilting drains and sewers.
jet firmly planted in the base of the pipe where the silt deposits collect and The heavy forged brass construction keeps the jet firmly planted in the
blasts them back towards the manhole. base of the pipe where the silt deposits collect and blasts them back
Width approx. 72 mm. Weight 1.5 kg. towards the manhole.
Max. 420 bar / 150° C / 80 l/min. Width approx. 88 mm. Weight 2.5 kg.
1/4"-nozzles need to be assembled under 45° to achieve best cleaning Max. 350 bar / 90° C / 80 l/min.
results. Select nozzle size according to pressure and flow rate of the Select rotor nozzle size symmetric according to pressure and flow rate of
machine. the machine.
R+M Nr. R+M Nr.
010 000 399 1/2" F 2 x 1/4" F NPT 200 049 410 3/8" F 2 x 1/4" M

Our rotating nozzles are on page 283.

Rotating nozzle adaptor

Designed for connecting the ST-357 rotating nozzle to a sewer cleaning
hose. Hardened stainless steel body with extra sharp edges.
Max. 400 bar
For ST-357 rotating nozzle
Possible jet configurations
cleaning efficiency
jet configuration thrust desilting side front

R+M Nr.
200 049 405 1/4" F 1/4" M

191
