Sewer cleaning & sewer cleaning nozzles 08

Sewer cleaning nozzles
Rotating nozzles RT . 1,000 bar Rotating nozzles RH . 1,000 bar

RT 100 50 12 35 g RH 100 63 12 42 g

Stainless steel. Rotating body hp-bronze. Compact model, universally Stainless steel. Rotating body hp-bronze. Compact model, universally
applicable. Extreme cleaning performance, removes hard deposits. applicable. Extreme cleaning performance, removes hard deposits.
Pressure max. 1,000 bar Pressure max. 1,000 bar
R+M Nr. side jet front jet R+M Nr. side jet
652 710 006 RT 100 6 l/100 bar 1/8" F 2 2 652 810 006 RH 100 6 l/100 bar 1/8" F 2
652 710 014 RT 100 14 l/100 bar 1/8" F 2 2 652 810 010 RH 100 10 l/100 bar 1/8" F 2
652 810 014 RH 100 14 l/100 bar 1/8" F 2
Cone shape nozzles LK . 500 bar * Nozzle inserts solid stream VS . 500 bar

LK 200 57 17 60 g VS 200 6 2.5
LK 400 65 24 200 g
VS 300 8 3.0
LK 500 75 32 300 g VS 400 10 4.0
LK 600 90 41 500 g
Stainless steel. Extremely high impact force. Long reach. Stainless steel.
Pressure max. 500 bar. Applications: cleaning of shafts. Pressure max. 500 bar
Delivery time of approx. 3 - 4 weeks
R+M Nr. orifice R+M Nr. orifice
652 400 01 LK 200 2 - 5 mm 1/4" M 652 600 02 VS 200 0.6 - 2.0 mm M6
652 400 02 LK 400 3 - 6 mm 1/2" M 652 600 03 VS 300 0.6 - 2.5 mm M8
652 400 03 LK 500 3 - 7 mm 3/4" M 652 600 04 VS 400 0.6 - 3.8 mm M10
652 400 04 LK 600 4 - 8 mm 1" M

* When placing an order, please state flow rate + pressure!

Symbols type thread pipe flow weight diameter length mm inlet outlet height
