High pressure hoses & hose fittings 07

Hose holder
Hose holder

125
Holding capacity 1/2" = 40 m / 3/4" = 30 m. Hole Holding capacity 1/2" = 40 m / 3/4" = 30 m. Hole
size 140 mm. W x H x D = 260 x 170 x 170 mm size 140 mm. W x H x D = 280 x 140 x 130 mm Ø 9
R+M Nr. R+M Nr.
110 00 plastic 110 05 powder-coated steel Ø 8 200
160
Hose holder aluminium
360
Holding capacity 1/2" = 40 m / 3/4" = 30 m. Hole
size 125 mm. W x H x D = 360 x 200 x 170 mm
R+M Nr.
110 06 polished stainless steel, 1.4301
Hose holder

R+M Nr. holding capacity
110 01 S 1/4" = 30 m / 3/8" = 20 m 155 77 188 145 70 5.5
110 02 M 3/8" = 30 m / 1/2" = 20 m 255 107 266 200 108 6.0 Holder with hooks. Suitable for scaffolding
110 03 L 1/2" = 30 m / 3/4" = 20 m 272 145 348 255 143 8.0 R+M Nr.
110 031 XL 3/4" = 30 m / 1" = 20 m 366 162 417 307 187 10.0 110 10 zinc-plated steel
Hose press

252

396 322

R+M Nr. pressing jaws incl. Spare pressing jaws
300 0 5 sets (12 - 27 mm) press area R+M Nr.
The P16 HP hose press is an innovative, high quality machine which is P16 HP-10 * 10 - 12 mm 300 001 0
especially designed for the assembly and repair of hose lines. The handling P16 HP-12 12 - 14 mm 300 001 2
of the press is easily learnt. Fundamental features of the P16 HP: P16 HP-14 14 - 16 mm 300 001 4
» access to press head on both sides P16 HP-16 16 - 19 mm 300 001 6
» compact model P16 HP-19 19 - 23 mm 300 001 9
» two-stage hand pump P16 HP-23 23 - 27 mm 300 002 3
» variable adjustment of press measures P16 HP-27 * 27 - 31 mm 300 002 7
» check of press measures by signal light P16 HP-31 * 31 - 36 mm 300 003 1
» carrying handle Technical specifications
» integrated drawer in the housing for storing the pressing jaws length of basic jaws 64 mm
max. opening diameter min. press diameter + 20 mm
press performance 2-steel wire hose up to DN 25
press area 10 - 45 mm
max. press power 720 kN
power 3.62 cm / 0.90 cm
pressure 14 bar / 630 bar
* pressing jaws excluded weight (without oil) 20 kg
Symbols diameter material type shipment by truck nominal diameter thread
