Lances 10

Lances
ST-001

1/4" M. Lance with male thread. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
070 004 008 1/4" M 400 mm stainless steel 070 000 076 1/4" M 400 mm zinc-plated steel
070 004 338 1/4" M 433 mm stainless steel 070 000 026 1/4" M 431 mm zinc-plated steel
070 005 008 1/4" M 500 mm stainless steel 070 000 030 1/4" M 500 mm zinc-plated steel
070 006 008 1/4" M 600 mm stainless steel 070 000 040 1/4" M 600 mm zinc-plated steel
070 008 008 1/4" M 800 mm stainless steel 070 000 050 1/4" M 800 mm zinc-plated steel
070 010 008 1/4" M 1,000 mm stainless steel 070 000 060 1/4" M 1,000 mm zinc-plated steel
070 012 008 1/4" M 1,200 mm stainless steel 070 000 070 1/4" M 1,200 mm zinc-plated steel
070 015 008 1/4" M 1,500 mm stainless steel 070 000 080 1/4" M 1,500 mm zinc-plated steel
070 020 008 1/4" M 2,000 mm stainless steel 070 000 090 1/4" M 2,000 mm zinc-plated steel

M22 M. Lance with nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
512 903 9 1/4" F NPT 430 mm stainless steel 512 903 1/4" F NPT 430 mm zinc-plated steel
513 103 9 1/4" F NPT 500 mm stainless steel 513 103 1/4" F NPT 500 mm zinc-plated steel
513 203 9 1/4" F NPT 600 mm stainless steel 513 203 1/4" F NPT 600 mm zinc-plated steel
513 303 9 1/4" F NPT 800 mm stainless steel 513 303 1/4" F NPT 800 mm zinc-plated steel
513 403 9 1/4" F NPT 1,000 mm stainless steel 513 403 1/4" F NPT 1,000 mm zinc-plated steel

M22 M. Lance with nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
513 203 91 1/4" F NPT 600 mm stainless steel 513 203 1 1/4" F NPT 600 mm zinc-plated steel
513 303 91 1/4" F NPT 800 mm stainless steel 513 303 1 1/4" F NPT 800 mm zinc-plated steel
513 403 91 1/4" F NPT 1,000 mm stainless steel 513 403 1 1/4" F NPT 1,000 mm zinc-plated steel

Symbols outlet insulation length material nozzle thread
