Page 246 - RM_2022

Lances 10

Lances
ST-001 with vented handle ST-9

Lance with insulation ST-9. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 29 1/4" M 380 mm 500 mm stainless steel 511 20 1/4" M 380 mm 500 mm zinc-plated steel
511 39 1/4" M 380 mm 600 mm stainless steel 511 30 1/4" M 380 mm 600 mm zinc-plated steel
511 49 1/4" M 380 mm 800 mm stainless steel 511 40 1/4" M 380 mm 800 mm zinc-plated steel
511 59 1/4" M 380 mm 1,000 mm stainless steel 511 50 1/4" M 380 mm 1,000 mm zinc-plated steel
511 69 1/4" M 380 mm 1,200 mm stainless steel 511 60 1/4" M 380 mm 1,200 mm zinc-plated steel
511 79 1/4" M 380 mm 1,500 mm stainless steel 511 70 1/4" M 380 mm 1,500 mm zinc-plated steel
511 719 1/4" M 760 mm 1,500 mm stainless steel 511 71 1/4" M 760 mm 1,500 mm zinc-plated steel
511 99 1/4" M 760 mm 2,000 mm stainless steel 511 90 1/4" M 760 mm 2,000 mm zinc-plated steel

1/4" M. Lance with vented handle ST-9 and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 201 9 1/4" F NPT 380 mm 500 mm stainless steel 511 201 1/4" F NPT 380 mm 500 mm zinc-plated steel
511 301 9 1/4" F NPT 380 mm 600 mm stainless steel 511 301 1/4" F NPT 380 mm 600 mm zinc-plated steel
511 401 9 1/4" F NPT 380 mm 800 mm stainless steel 511 401 1/4" F NPT 380 mm 800 mm zinc-plated steel
511 501 9 1/4" F NPT 380 mm 1,000 mm stainless steel 511 501 1/4" F NPT 380 mm 1,000 mm zinc-plated steel
511 601 9 1/4" F NPT 380 mm 1,200 mm stainless steel 511 601 1/4" F NPT 380 mm 1,200 mm zinc-plated steel
511 701 9 1/4" F NPT 760 mm 1,500 mm stainless steel 511 701 1/4" F NPT 760 mm 1,500 mm zinc-plated steel
511 901 9 1/4" F NPT 760 mm 2,000 mm stainless steel 511 901 1/4" F NPT 760 mm 2,000 mm zinc-plated steel

1/4" M. Lance with vented handle ST-9 and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 401 19 1/4" F NPT 380 mm 800 mm stainless steel 511 401 1 1/4" F NPT 380 mm 800 mm zinc-plated steel
511 501 19 1/4" F NPT 380 mm 1,000 mm stainless steel 511 501 1 1/4" F NPT 380 mm 1,000 mm zinc-plated steel
511 601 19 1/4" F NPT 380 mm 1,200 mm stainless steel 511 601 1 1/4" F NPT 380 mm 1,200 mm zinc-plated steel
511 701 19 1/4" F NPT 760 mm 1,500 mm stainless steel 511 701 1 1/4" F NPT 760 mm 1,500 mm zinc-plated steel
511 901 19 1/4" F NPT 760 mm 2,000 mm stainless steel 511 901 1 1/4" F NPT 760 mm 2,000 mm zinc-plated steel

Symbols outlet length material insulation thread
