Page 250 - RM_2022

Lances 10

Lances

K
M22 F. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
514 19 nozzle protector 380 mm 500 mm stainless steel 514 10 nozzle protector 380 mm 500 mm zinc-plated steel
514 29 nozzle protector 380 mm 600 mm stainless steel 514 20 nozzle protector 380 mm 600 mm zinc-plated steel
514 39 nozzle protector 380 mm 800 mm stainless steel 514 30 nozzle protector 380 mm 800 mm zinc-plated steel
514 59 nozzle protector 380 mm 1,000 mm stainless steel 514 50 nozzle protector 380 mm 1,000 mm zinc-plated steel
514 69 nozzle protector 380 mm 1,200 mm stainless steel 514 60 nozzle protector 380 mm 1,200 mm zinc-plated steel
514 79 nozzle protector 380 mm 1,500 mm stainless steel 514 70 nozzle protector 380 mm 1,500 mm zinc-plated steel
514 89 nozzle protector 760 mm 2,000 mm stainless steel 514 80 nozzle protector 760 mm 2,000 mm zinc-plated steel

K

M22 F. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
514 391 nozzle protector 380 mm 800 mm stainless steel 514 301 nozzle protector 380 mm 800 mm zinc-plated steel
514 591 nozzle protector 380 mm 1,000 mm stainless steel 514 501 nozzle protector 380 mm 1,000 mm zinc-plated steel
514 691 nozzle protector 380 mm 1,200 mm stainless steel 514 601 nozzle protector 380 mm 1,200 mm zinc-plated steel
514 791 nozzle protector 380 mm 1,500 mm stainless steel 514 701 nozzle protector 380 mm 1,500 mm zinc-plated steel
514 891 nozzle protector 760 mm 2,000 mm stainless steel 514 801 nozzle protector 760 mm 2,000 mm zinc-plated steel

K
M22 F swivel. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
514 119 nozzle protector 380 mm 500 mm stainless steel 514 11 nozzle protector 380 mm 500 mm zinc-plated steel
514 519 nozzle protector 380 mm 1,000 mm stainless steel 514 510 nozzle protector 380 mm 1,000 mm zinc-plated steel
514 719 nozzle protector 380 mm 1,500 mm stainless steel 514 71 nozzle protector 380 mm 1,500 mm zinc-plated steel
514 819 nozzle protector 760 mm 2,000 mm stainless steel 514 81 nozzle protector 760 mm 2,000 mm zinc-plated steel

K
M22 F swivel. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
514 519 1 nozzle protector 380 mm 1,000 mm stainless steel 514 511 nozzle protector 380 mm 1,000 mm zinc-plated steel
514 719 1 nozzle protector 380 mm 1,500 mm stainless steel 514 711 nozzle protector 380 mm 1,500 mm zinc-plated steel
514 819 1 nozzle protector 760 mm 2,000 mm stainless steel 514 811 nozzle protector 760 mm 2,000 mm zinc-plated steel

Symbols outlet length material insulation
