Lances 10

Lances with ergonomic swivel screw coupling
Lances with insulation ST-22

K
M22 F swivel. Lance with insulation ST-22 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. spray gun R+M Nr. spray gun
514 529 1 standard 410 mm 1,000 mm stainless steel 514 539 1 servopress 410 mm 1,000 mm stainless steel
Twin lances with moulded handle

K
M22 F swivel. Lance with moulded handle, valve ST-54 aside and nozzle protector without tip. Max. 310 bar / 150 °C
R+M Nr. R+M Nr.
517 608 5 nozzle protector 300 mm 980 mm zinc-plated steel

suitable for standard spray guns K

M22 F swivel. ST-85 Push & Pull lance with ergonomic swivel screw coupling suitable for standard spray guns. Max. 210 bar / 150 °C
R+M Nr. R+M Nr.
200 085 645 nozzle protector 850 mm M22 F swivel stainless steel 200 085 745 nozzle protector 850 mm M22 F swivel zinc-plated steel
200 085 935 nozzle protector 1,000 mm M22 F swivel stainless steel 200 085 925 nozzle protector 1,000 mm M22 F swivel zinc-plated steel
200 085 685 nozzle protector 1,500 mm M22 F swivel stainless steel 200 085 785 nozzle protector 1,500 mm M22 F swivel zinc-plated steel
200 085 687 nozzle protector 2,000 mm M22 F swivel stainless steel

suitable for servopress spray guns K
M22 F swivel. ST-85 Push & Pull lance with ergonomic swivel screw coupling suitable for servopress spray guns. Max. 210 bar / 150 °C
R+M Nr. R+M Nr.
200 085 646 nozzle protector 850 mm M22 F swivel stainless steel 200 085 746 nozzle protector 850 mm M22 F swivel zinc-plated steel
200 085 936 nozzle protector 1,000 mm M22 F swivel stainless steel 200 085 926 nozzle protector 1,000 mm M22 F swivel zinc-plated steel
200 085 686 nozzle protector 1,500 mm M22 F swivel stainless steel 200 085 786 nozzle protector 1,500 mm M22 F swivel zinc-plated steel
200 085 688 nozzle protector 2,000 mm M22 F swivel stainless steel
Lances with vented handle ST-9

K
M22 F swivel. Lance with ergonomic swivel screw coupling, vented handle ST-9 & grip and nozzle protector (M20x1) without tip.
Max. 650 bar / 150 °C
R+M Nr. R+M Nr.
200 146 550 nozzle protector 700 mm M22 F swivel stainless steel
