10 Lances
Lances
ST-001 with vented handle ST-9
A
Plug KW. Lance with vented handle ST-9 and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 405 9 1/4" F NPT 380 mm 800 mm stainless steel 511 405 1/4" F NPT 380 mm 800 mm zinc-plated steel
511 505 9 1/4" F NPT 380 mm 1,000 mm stainless steel 511 505 1/4" F NPT 380 mm 1,000 mm zinc-plated steel
A
Plug KW. Lance with vented handle ST-9 and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 405 91 1/4" F NPT 380 mm 800 mm stainless steel 511 405 1 1/4" F NPT 380 mm 800 mm zinc-plated steel
511 505 91 1/4" F NPT 380 mm 1,000 mm stainless steel 511 505 1 1/4" F NPT 380 mm 1,000 mm zinc-plated steel
A
Plug KW. Lance with insulation ST-9, grip and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 705 9 1/4" F NPT 760 mm 1,500 mm stainless steel 511 705 1/4" F NPT 760 mm 1,500 mm zinc-plated steel
511 905 9 1/4" F NPT 760 mm 2,000 mm stainless steel 511 905 1/4" F NPT 760 mm 2,000 mm zinc-plated steel
A
Plug KW. Lance with insulation ST-9, grip and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 705 91 1/4" F NPT 760 mm 1,500 mm stainless steel 511 705 1 1/4" F NPT 760 mm 1,500 mm zinc-plated steel
511 905 91 1/4" F NPT 760 mm 2,000 mm stainless steel 511 905 1 1/4" F NPT 760 mm 2,000 mm zinc-plated steel
Symbols outlet length material insulation
