Page 249 - RM_2022

10 Lances

Lances
ST-001 with vented handle ST-9

M22 M. Lance with vented handle ST-9 and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 203 9 1/4" F NPT 380 mm 500 mm stainless steel 511 203 1/4" F NPT 380 mm 500 mm zinc-plated steel
511 503 9 1/4" F NPT 380 mm 1,000 mm stainless steel 511 503 1/4" F NPT 380 mm 1,000 mm zinc-plated steel
511 703 9 1/4" F NPT 380 mm 1,500 mm stainless steel 511 703 1/4" F NPT 380 mm 1,500 mm zinc-plated steel
511 803 9 1/4" F NPT 760 mm 2,000 mm stainless steel 511 803 1/4" F NPT 760 mm 2,000 mm zinc-plated steel

M22 M. Lance with vented handle ST-9 and nozzle protector ST-10 without high pressure nozzle. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
511 503 91 1/4" F NPT 380 mm 1,000 mm stainless steel 511 503 1 1/4" F NPT 380 mm 1,000 mm zinc-plated steel
511 703 91 1/4" F NPT 380 mm 1,500 mm stainless steel 511 703 1 1/4" F NPT 380 mm 1,500 mm zinc-plated steel
511 803 91 1/4" F NPT 760 mm 2,000 mm stainless steel 511 803 1 1/4" F NPT 760 mm 2,000 mm zinc-plated steel

ST-001 with vented handle ST-9

Plug KW. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
514 594 nozzle protector 380 mm 1,000 mm stainless steel
Nozzle protector

K K

Nozzle protector with M22 F. Nozzle protector with plug KW.
Without tip. Max. 400 bar / 150 °C Without tip. Max. 400 bar / 150 °C
R+M Nr. R+M Nr.
561 41 559 105

248
