10 Lances

Lances with ergonomic swivel screw coupling
» Lances suitable for Kärcher spray guns.
» The lance has an ergonomic and conical swivel screw coupling operating
as a connection piece between the lance and the spray gun. The new
design offers a smooth transition from the spray gun to the lance.
» Rotating by 360° under pressure.
» All materials are rust-free and of premium quality.
» The hand screw coupling is made out of shock-resistant plastics and
equipped with a brazen thread. The internal nipple of the hand screw spray gun - standard K
coupling is made out of stainless steel.
» Nozzle protector without tip.

spray gun - servopress K

ST-2635 - standard K ST-2300 - standard K

Lances with vented handle ST-9

K
M22 F swivel. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. spray gun R+M Nr. spray gun
514 149 standard 380 mm 500 mm stainless steel 514 159 servopress 380 mm 500 mm stainless steel
514 249 standard 380 mm 600 mm stainless steel 514 559 servopress 380 mm 1,000 mm stainless steel
514 549 standard 380 mm 1,000 mm stainless steel
514 749 standard 380 mm 1,500 mm stainless steel

K

M22 F swivel. Lance with vented handle ST-9 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. spray gun R+M Nr. spray gun
514 349 1 standard 380 mm 800 mm stainless steel 514 559 1 servopress 380 mm 1,000 mm stainless steel
514 549 1 standard 380 mm 1,000 mm stainless steel
514 649 1 standard 380 mm 1,200 mm stainless steel
514 749 1 standard 380 mm 1,500 mm stainless steel
Lances with insulation ST-22

K
M22 F swivel. Lance with insulation ST-22 and nozzle protector without tip. Max. 400 bar / 150 °C
R+M Nr. spray gun R+M Nr. spray gun
514 129 * standard 310 mm 500 mm stainless steel 514 139 * servopress 310 mm 500 mm stainless steel
514 529 standard 410 mm 1,000 mm stainless steel 514 539 servopress 410 mm 1,000 mm stainless steel

Symbols inlet outlet length material insulation
* limited stock
