Nozzles & washing accessories 11
Mud suckers
The high-performance mud sucker for all
standard pressure washers
extracts stones (up to 20 mm), mud, dirt, sand, algae & sediment.
Operating pressure min. 80 bar at 7 l/min. Suction power of approx.
8,000 to 18,000 l/h. Spiral hose: DN 38 mm, length 5 m
A
M22 M M21 M 1/2" M M18 M Plug KW
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. HP hose
04 545 504 0 545 514 0 545 524 0 545 534 0 545 545 5 055 5 m
045 545 504 5 545 514 5 545 524 5 545 534 5 545 546 0 06 5 m
05 545 505 0 545 515 0 545 525 0 545 535 0 Performance chart
055 545 505 5 545 515 5 545 525 5 545 535 5
high pressure cleaner capacity of mud sucker
06 545 506 0 545 516 0 545 526 0 545 536 0
065 545 506 5 545 516 5 545 526 5 545 536 5 capacity capacity
07 545 507 0 545 517 0 545 527 0 545 537 0 100 bar 10 l/min ca. 170 l/min ca. 10,000 l/h
08 545 508 0 545 518 0 545 528 0 545 538 0 150 bar 12 l/min ca. 220 l/min ca. 13,000 l/h
10 545 501 0 200 bar 15 l/min ca. 300 l/min ca. 18,000 l/h
Symbols pressure flow nozzle inlet outlet length
