11 Nozzles & washing accessories

Wash brushes

A
A= 260. B= 230 x 80 mm. Hog hair. A= 260. B= 230 x 80 mm. Hog hair. A= 260. B= 230 x 80 mm. Hog hair. With stainless
Max. 50 °C Max. 50 °C steel frame. Max. 50 °C
R+M Nr. C R+M Nr. C R+M Nr. C
523 703 60 mm 1/8" M 200 023 700 60 mm 1/4" F 200 023 730 60 mm 1/4" F

K
A= 260. B= 230 x 80 mm. Hog hair.
Max. 50 °C
R+M Nr. C
523 701 60 mm M18 x 1.5 F

The original Vorwerk lances & wash brushes

Extension pipe with water flow
R+M Nr.
523 790 1 1,000 mm 1/4" M 1/4" F
523 790 2 1,500 mm 1/4" M 1/4" F
523 790 3 2,000 mm 1/4" M 1/4" F
Vorwerk wash brushes Adaptor

A= 300. B= 300 x 100 mm. Nylon A= 240. B= 230 x 80 mm. Hog hair Adaptor for lances with coarse thread.
R+M Nr. C R+M Nr. C Coarse thread : 1/4" M
523 780 60 mm 1/4" F 523 70 60 mm 1/4" F R+M Nr.
523 75 90 mm 1/4" F 010 003 610
Air injector

Brush. A= 260. B= 230 x 80 mm. Frame. 260 mm. 1/4" F : 1/4" M.
Hog hair Aluminium Flow at 100 bar
R+M Nr. C R+M Nr. R+M Nr.
523 72 60 mm 523 76 1/4" F 108 290 60 13 l/min 1.5
523 73 90 mm 108 290 20 34 l/min 2.5
Symbols length inlet outlet diameter thread nozzle flow

300
