Nozzles & washing accessories 11

Vario nozzles and triple nozzles

K
1/4" F. Housing black. Max. 250 bar / 80 °C M18 F. Housing black. Max. 250 bar / 80 °C
R+M Nr. R+M Nr.
657 545 045 657 545 1 045
657 555 055 657 555 1 055
657 560 06 657 560 1 06

Functional principle triple nozzles

high pressure zero angle high pressure broad angle 25° low pressure broad angle 40°

Adjustable nozzles
Mini adjustable nozzles R+M adjustable nozzles ST-51 adjustable nozzles Functional principle of
a adjustable nozzle

high pressure phase low pressure phase

R+M Nr. R+M Nr. R+M Nr.
657 20 1/4" F 1/4" F 657 30 1/4" F 1/4" F 200 051 530 1/4" F 1/4" F

Universal bracket

new 110
10

55 25

R+M Nr. Stainless steel bracket for wall mounting
710 400 097

* lance
