05 Burner equipment & coils

Ignition electrodes
37,0
65,0
130,0
6,3 9,8 76,0 1,9 4,0 6,4 180,0 1,7
17,8 3,5 19,0
107,0 18,0
R+M Nr. suitable for R+M Nr. suitable for R+M Nr. suitable for
852 10 Kärcher 852 12 Kärcher 124 408 0 Kränzle
64,5
30,5 25,5 28,0 30,0
6,3 94,0 9,6 1,6
10,8 8,8 3,0 12,8 10,7 3,0
30,0 21,8
34,0
R+M Nr. suitable for R+M Nr. suitable for R+M Nr. suitable for
851 30 SIAL 850 60 Alto 851 35 SIRIO
50,0 40,0
35,0
22,5 18,0
6,3 9,0 80,0 1,7
11,0 11,0 3,0 2,0 20,0
35,0
50,0 48,0
R+M Nr. suitable for R+M Nr. suitable for R+M Nr. suitable for
851 10 LAVORWASH 851 55 Lavor 851 60 Idromatic
43,0 50,0
35,0 new 30,0 26,0
6,3 9,0 93,0 1,7
3,0
20,0 76,0 10,7 8,7 3,0
47,0
110,0
R+M Nr. suitable for R+M Nr. suitable for R+M Nr. suitable for
851 65 Idromatic 851 00 PORTO 852 15 MAER

Adjustment of electrodes
4 mm

from side from top
1 Electrodes have to be positioned close
to the atomized spray of fuel without
getting in touch with it (ends have to stay
dry).
2 There has to be sufficient space between
the electrodes and the fuel nozzle as well as
the flame control to avoid a flash over of the
ignition spark.

R+M high quality spare parts are obtained from well-established manufacturers. As a rule they are no original spare parts. The original order numbers and the
indication of other information are exclusively for your guidance and furthermore they are not intended for the general use, e.g. invoices addressed to end users.
In case of mentioning the original order numbers in your orders it can not be assumed that the products ordered are original spare parts. Original spare parts are
supplied when they are especially offered as those in our catalogue or in other mailing pieces such as special offers or newsletters.
