Burner equipment & coils 05

Fuel nozzles

Hollow (1 gal = 3.785 litres) Half hollow (1 gal = 3.785 litres)
Steinen (H) Danfoss (H) Delavan (A) Danfoss (B) Delavan (W)
60° 80° 60° 80° 45° 60° 80° 45°
US gph R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. US gph R+M Nr. R+M Nr. R+M Nr. R+M Nr.
0.50 G 677 41 1.00 G 675 32 677 82
0.75 G 675 11 679 19 * 1.25 G
0.85 G 665 31 675 21 677 71 1.35 G 675 52 679 212 1
1.00 G 665 41 675 31 677 81 679 201 1.50 G 678 12 679 213 1
1.10 G 675 36 677 851 1.75 G 679 204 1*
1.25 G 665 51 668 01 675 41 677 91 679 202 2.00 G 675 82
1.35 G 665 61 668 11 675 51 2.25 G 679 217 1*
1.50 G 665 71 675 61 678 11
1.75 G 665 91 675 71 678 21
2.00 G 666 01 675 81
2.25 G 666 11 668 61 675 91 678 41
2.50 G 666 21 668 71 676 01
Solid (1 gal = 3.785 litres)
Steinen (S/ST) Danfoss (S) Delavan (B)
45° 60° 80° 60° 80° 45° 60°
US gph R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
0.50 G 660 42 665 10 667 60 674 90 677 40 679 10 * Packing units
0.60 G 665 11 Steinen 12 pieces
0.65 G 660 45 665 15 667 65 675 00 677 50 Danfoss 10 pieces
0.75 G 660 46 665 20 667 70 675 10 677 60 Delavan 12 pieces
0.85 G 660 47 665 30 667 80 675 20 677 70 679 30 *
1.00 G 660 49 665 40 667 90 675 30 677 80
1.10 G 675 35 677 85
1.25 G 660 50 665 50 668 00 675 40 677 90 679 211 * 679 43
1.35 G 665 60 668 10 675 50 678 00 679 44
1.50 G 660 60 665 70 668 20 675 60 678 10 679 213 679 45
1.65 G 660 62 665 80 668 30 679 214 679 47
1.75 G 660 63 665 90 668 40 675 70 678 20 679 46
2.00 G 660 80 666 00 668 50 675 80 678 30
2.25 G 660 85 666 10 668 60 675 90 678 40 679 49 *
2.50 G 666 20 668 70 676 00 678 50
2.75 G 666 40 668 90 676 05 678 60 Further nozzles in
3.00 G 669 00 676 15 different packing units
3.50 G 666 50 are available on request.
4.00 G 666 60

Fuel nozzles manufacturer comparison chart

Steinen Danfoss Monarch Delavan Hago Fluidics

Solid S/ST S/SR AR/R B ES/B/P S/SF

Hollow H H/HR NS/PL A H H/HF

Half hollow Q B PLS/PLP W SS -
