Page 89 - RM_2022

05 Burner equipment & coils

Fuel pumps drive pegs
Coupling for shaft 6 mm Coupling for shaft 8 mm short Coupling for shaft 8 mm long
17,5 14,5
14,5 16,0
22,0
9,8 4,3 11,0 14,5
11,0 17,5
14,0 11,0
R+M Nr. R+M Nr. R+M Nr.
822 30 6 mm 822 25 8 mm 822 35 8 mm
Fuel solenoid valves Burner motors

Rapa BV 01 without cable Motor with pump shaft 32 mm Flange for burner motors

80

40

13
122
R+M Nr.
NC. Normally closed. Max. 24 bar / 60 °C 811 01 NEMA 1 172 mm
R+M Nr. coil Output max. 150 W - 1.3 A. Cable 500 mm. Right 811 02 NEMA 2 184 mm
830 10 1/8" F 24 V or left rotation
830 20 1/8" F 230 V R+M Nr. Cable connection for
830 40 1/4" F 230 V 811 03 230 V
motor left and right
Spare coils Rapa Cable with connector Flange with pump shaft 32 mm
220 V 220 V

32
124 134
13

F left rotation right rotation
Output max. 110 W - 0.88 A. Cable 500 mm. function function
Rapa M13 Left rotation brown+blue phase brown+white phase
black+white neutral black+blue neutral
R+M Nr. R+M Nr. R+M Nr.
yellow/green ground yellow/green ground
830 70 230 V 832 40 1,050 mm 810 00 230 V
Fuel filter

Fuel filter
6,0
7,7 103,0

36,3

R+M Nr.
829 05

Symbols diameter type voltage thread length colour
