05 Burner equipment & coils

Fuel pumps Suntec Fuel pumps Delta
Pumps with solenoid valve Pumps with solenoid valve Pumps without solenoid valve

Coil VM Coil VU / A
R+M Nr. R+M Nr.
827 90 24 V 824 94 24 V
827 95 230 V 824 95 230 V
Pump VM. Single line intake or double line intake. Pump A. Single line intake or double line intake. Pump A. Single line intake or double line intake.
Pressure adjustable 7 - 14 bar Pressure adjustable 6 - 20 bar Pressure adjustable 6 - 20 bar

8 mm
8 mm 8 mm

R+M Nr. coil hub R+M Nr. coil hub R+M Nr. coil hub
827 00 AS47C 1538 24 V 32 mm 824 31 A1L2 24 V 32 mm 824 04 AD1L2 - 32 mm
827 10 AS47C 1538 230 V 32 mm 824 30 A1L2 230 V 32 mm

8 mm
8 mm 8 mm

R+M Nr. coil hub R+M Nr. coil hub R+M Nr. coil hub
827 15 AS47D 1539 230 V 32 mm 824 32 A1R2 24 V 32 mm 824 05 AD1R2 - 32 mm
824 33 A1R2 230 V 32 mm
Universal with solenoid valve. Left/right
Spare parts Suntec and Delta fuel pumps

Coil VU / A
Gasket for cover (round). Year of manufacture Filter element
R+M Nr. until 2001
824 94 24 V
R+M Nr. R+M Nr.
824 95 230 V
827 992 Suntec 827 50 Suntec
Pump VU. Single line intake or double line intake. 824 90 Delta
Cable 700 mm. Pressure adjustable 6 - 18 bar 824 96 Delta A

8 mm

Gasket for cover (square). Year of manufacture Gasket for cover
R+M Nr. coil hub from 2001
824 40 VU1LR2 24 V 32 mm R+M Nr. R+M Nr.
824 45 VU1LR2 230 V 32 mm 827 993 Suntec 824 93 Delta
Symbols type voltage length diameter
