04 Electrical equipment

Motor control easywash365+
Motor control for the operation of motors with 4 - 7.5 kW power at 400 VAC,
50 Hz, IP 65. RAL 7035.
new
H x W x D 380 x 380 x 210 mm.
Supply: 400VAC, 50Hz, 3Ph / N / PE with main switch (cam switch) 25A. Con-
trol voltage conditioning 24VDC, 2.5A with backup fuse 2A.
Motor outlet with power contactor 7.5kW and wide-range motor protection
switch 8-32A.
LOGO small control unit.
1 operating hours counter (IP 65) and 2 command and signaling devices
built into the door

R+M Nr.
920 001 380 14 kg

Coin box easywash365+ including control box

Coin box easywash365+ including control box Control box easywash365+

R+M coin box, mechanical, feat. money return, incl. control box, IP 66, RAL Control box, IP 66, RAL 7035. H x W x D 300 x 300 s 155 mm. Feat. 2 m supply
7035 feat. 2 m supply cable with CEE-plug, 16 A, 400 VAC, 50 Hz, 3 PH/N/PE. cable with CEE-plug 16 A, 400 VAC, 50 Hz, 3 Ph/N/PE.
Control voltage processing 24 VAC, 20 VA with 2 automatic circuit breakers. Control voltage processing 24 VAC, 20 VA with 2 automatic circuit breakers.
Motor output with power contactor 7.5 kW, wired to CEE add-on box. Motor output with power contactor 7.5 kW, wired to CEE add-on box.
Feat. a time relay for pulse stretching 0.05 s - 10 h. Feat. a time relay for pulse stretching 0.05 s - 10 h.
Excl. control cable Excl. control cable

R+M Nr. money coin box control box R+M Nr.
925 513 803 chip (profiled) 260 x 160 x 110 300 x 300 x 155 925 510 000 9.6 kg
925 513 805 50 Cent 260 x 160 x 110 300 x 300 x 155
CEE Plug
925 513 801 1 € 260 x 160 x 110 300 x 300 x 155
925 513 802 2 € 260 x 160 x 110 300 x 300 x 155 new
Control cable new

5 wires, UV-resistant. Sold by metre. 400V / 16A / 3PNE. IP 44. With screw terminals up to a maximum of 2.5 mm²
R+M Nr. R+M Nr.
925 510 001 5 G 1.5 mm 2 901 338 001

Symbols type weight
