03 High pressure equipment
t
e equipmen
Pressure switches
Condor / Fanal PR 5 Example of use
with two pressure switches
103 78 49 26 1 - Starting phase

40 bar
83 25 bar bar bar

50

Contact of pressure switch (40 bar) is activated
Contact 10 A - 380 V. Thread 3/8" F. Contact 5 A - 250 V. Cable 950 mm. Thread 1/4" M. and by this way the cleaner can be started.
Max. 250 bar / 90 °C Max. 250 bar / 90 °C
2 - High pressure phase
R+M Nr. R+M Nr. start-up pressure
911 50 FF4-4 0.22 - 4 bar 110 mm 912 515 blue 15 bar
40 bar
911 40 FF4-32 2 - 32 bar 110 mm 912 525 red 25 bar
25 bar bar bar
911 20 FF4-250 30 - 250 bar 140 mm 912 540 black 40 bar
Diaphragm pressure switches SW 27 Connector PG 9 Spare parts

Reaching 25 bar the pressure switch (25 bar)
changes the operating condition and secures
the operation of the cleaner while pressure
switch (40 bar) is deactivated.
3 - Stop phase

Stainless steel. Contact 4 A - 24 V - 250 V. EPDM Suitable for diaphragm Micro switches 40 bar
seals. Usable as dry running protection. pressure switch 25 bar bar bar
Max. 300 bar / 90 °C
R+M Nr. R+M Nr. R+M Nr.
913 186 203 1/4" M 0.5 - 5 bar 913 118 002 912 00
913 186 206 1/4" M 0.5 - 10 bar
During the bypass phase water circulates in
the pump without pressure.
The pressure switch (25 bar) opens and the
When exchanging the pressure switch please cleaner stops. At the same time there is still
high pressure between the regulation valve
check the accumulator and if necessary exchange it.
and the gun.
The high pressure cleaner starts again when
operating the gun.

Pressure switches ST-7.1
» IP 65 protection class . Contacts: red and brown =
» Simultaneous N/O and N/C connection is normally closed / red and blue =
possible. normally open.
» The design of the micro switch allows compara- When used with 2 pressure swit-
bly high inrush current (20 Amps N/C, 15 Amps ches, the two blue cables serve
N/O). as control lines.
» The electrical capacity of the switch is 10.1
Amps (resistive load).
» Available switch points are 25 and 40 bar.
» No ingress of towing water into the environ-
ment of the microswitch possible.
R+M Nr.
Contact 10.1 A - 250 VAC. 200 007 800 40 bar black 1/4" M
Cable 950 mm. Max. 300 bar / 90 °C. IP65 200 007 801 25 bar red 1/4" M

Symbols thread type pressure colour height
