03 High pressure equipment
Suttner flow switches
ST-505 flow switches-5 "High-Flow" 210 bar
ST -5 flo w swit che ST
Floater ST-5 "High-Flow"
with hole
REED switch
R+M Nr. R+M Nr.
200 005 528 200 005 435
ST-5 "High-Flow". Floater with hole.
Contact 1 A - 250 V.
R+M Nr. mount closed/open cable
200 005 701 1/2" F vertical 5.2/4.2 80 60 l/min 1,200 mm
ST-505 flow switchesches 350 bar
ST -5 flo w swit
Floater ST-5 without
hole
REED switch
R+M Nr. R+M Nr.
200 005 518 200 005 435
Floater with hole. Contact 1 A - 250 V.
R+M Nr. mount closed/open cable
200 005 501 3/8" F vertical 3.4/2.9 80 30 l/min 1,200 mm
200 005 601 3/8" F horizontal or vertical 5.2/4.2 80 30 l/min 1,200 mm
Floater ST-5 without
hole
REED switch
R+M Nr. R+M Nr.
200 005 526 200 005 435
Floater without hole. Contact 1 A - 250 V.
R+M Nr. mount closed/open cable
200 005 558 3/8" F vertical 0.3/0.17 80 30 l/min 1,200 mm
ST-505 flow switches 600 bar
Floater ST-505 with hole
R+M Nr. cable
R+M Nr. 200 005 435 1,200 mm
200 005 301 200 005 438 3,500 mm
Floater VA with hole.
Contact 1 A - 250 V.
R+M Nr. mount closed/open cable
200 505 706 3/8" F vertical 3.3/1.8 80 30 l/min 1,200 mm
200 505 709 3/8" F vertical 2.9/1.7 80 30 l/min 3,600 mm
Floater ST-505 without
hole
R+M Nr. cable
R+M Nr. 200 005 435 1,200 mm
200 005 526 200 005 438 3,500 mm
Floater brass with hole.
Contact 1 A - 250 V.
R+M Nr. mount closed/open cable
200 505 708 3/8" F vertical 0.5/0.1 80 30 l/min 1,200 mm
200 505 711 3/8" F vertical 0,5/0.1 80 30 l/min 3,600 mm
Floater ST-505 without
hole
REED switch
R+M Nr. R+M Nr.
200 005 311 200 005 438
Floater VA without hole. Contact 1 A - 250 V
R+M Nr. mount closed/open cable
200 505 707 3/8" F vertical 1.8/1.3 80 30 l/min 1,200 mm
