High pressure equipment 03

easyfoam365+ injectors by Suttner
Injectors ST-160 Injectors ST-166

3/8" F : 3/8" M : 2 hose tails 9 mm. Injector for
applications with chemicals and foam.
3/8" F : 3/8" M : hose tail 9 mm. Injector for 3/8" F : 3/8" M : hose tail 9 mm.
The injector sucks in/admixes up to two chemi-
applications with chemicals and foam. The Injector ST-160 with metering valve ST-161.
cals at the same time.
chemical dosing is adjusted by 10 exchangeable Max. 350 bar / 90 °C
The chemical dosing is adjusted by 2 x 10 ex-
nozzle inserts (0.5 - 2.0 mm).
changeable nozzle inserts (0.5 - 2.0 mm).
Max. 350 bar / 90 °C
Max. 350 bar / 90 °C
R+M Nr. R+M Nr.
R+M Nr.
200 160 498 1.1 mm 200 160 599 1.1 mm
200 166 500 1.3 mm
200 160 499 1.2 mm 200 160 600 1.2 mm
200 166 510 1.6 mm
200 160 500 1.3 mm 200 160 601 1.3 mm
200 166 530 1.9 mm
200 160 505 1.4 mm 200 160 602 1.4 mm
200 160 510 1.5 mm 200 160 603 1.5 mm Valve lock
200 160 515 1.6 mm 200 160 604 1.6 mm
200 160 520 1.7 mm 200 160 605 1.7 mm
200 160 525 1.8 mm 200 160 606 1.8 mm
200 160 530 1.9 mm 200 160 607 1.9 mm
200 160 535 2.0 mm 200 160 608 2.0 mm
200 160 540 2.1 mm 200 160 609 2.1 mm
200 160 545 2.2 mm 200 160 610 2.2 mm
200 160 550 2.3 mm 200 160 611 2.3 mm Valve lock for metering valve ST-161
200 160 560 2.5 mm 200 160 613 2.5 mm R+M Nr.
200 160 575 2.8 mm 200 160 614 2.8 mm 040 003 566
Metering valves ST-161

Hose tail 9 mm : M14 M. Metering valve ST-161 Hose tail 9 mm : M14 M. Metering valve ST-161 Hose tail 9 mm : hose tail 9 mm.
suitable for being refitted in easyfoam365+ suitable for being refitted in easyfoam365+ Panel mount is possible
injectors (ST-160, ST-166, ST-167 and ST-168) injectors (ST-160, ST-166, ST-167 and ST-168)
R+M Nr. R+M Nr. R+M Nr.
200 161 500 blue (FKM) 200 161 515 grey (EPDM) 200 161 510 blue (FKM)
Exchangeable nozzle inserts ST-160 wall mount
new 140
110
22,5

30
Ø
6,5
Plastic. 10 nozzle inserts Plastic. 9 nozzle inserts (0.5 - 1.5 mm). Stainless steel. Incl. fastening
(0.5 - 2.0 mm). Incl. o-rings. material for the injector.
Incl. o-rings Incl. 1 insert without hole Fits for ST-160+161 and 166
R+M Nr. R+M Nr. R+M Nr.
200 163 340 200 163 335 200 160 160
