03 High pressure equipment

easyfoam365+ injectors by Suttner
Injectors ST-160 with metering valve ST-161

Coupling ST-45-250 stainless steel : plug Coupling ST-45-250 nickel-plated brass : plug M22 F : M22 M. Injector with metering valve
ST-45-250 stainless steel. Injector with metering ST-45-250 zinc-plated steel. Injector with ST-161, suction hose 2,000 mm and suction filter
valve ST-161, suction hose 2,000 mm and suction metering valve ST-161, suction hose 2,000 mm ST-31.
filter ST-31. Max. 250 bar / 90 °C and suction filter ST-31. Max. 250 bar / 90 °C Max. 350 bar / 90 °C
R+M Nr. R+M Nr. R+M Nr.
200 160 845 1.2 mm 200 160 860 1.2 mm 200 160 803 1.2 mm
200 160 846 1.3 mm 200 160 861 1.3 mm 200 160 804 1.3 mm
200 160 847 1.4 mm 200 160 862 1.4 mm 200 160 800 1.4 mm
200 160 848 1.5 mm 200 160 863 1.5 mm 200 160 801 1.5 mm
200 160 849 1.6 mm 200 160 864 1.6 mm 200 160 802 1.6 mm
200 160 850 1.7 mm 200 160 865 1.7 mm 200 160 805 1.7 mm
200 160 851 1.8 mm 200 160 866 1.8 mm 200 160 806 1.8 mm
200 160 852 1.9 mm 200 160 867 1.9 mm 200 160 808 2.0 mm
200 160 853 2.0 mm 200 160 868 2.0 mm 200 160 809 2.1 mm
200 160 854 2.1 mm 200 160 869 2.1 mm 200 160 810 2.2 mm
200 160 855 2.2 mm 200 160 870 2.2 mm 200 160 811 2.3 mm
200 160 856 2.3 mm 200 160 871 2.3 mm
Reinforced PVC hoses blue Suction filter ST-31 Accessories injectors

Max. 60 °C. Other dimensions are available on Filter without check Filter with check valve. Hose tail 9 mm : M14 M. 1/4" M : M14 M.
request valve. Plastic. Plastic. Check valve Check valve
Per metre Stainless steel weight Stainless steel weight
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
R+M Nr.
200 031 615 200 031 611 200 163 350 200 163 356
080 000 310 9 mm 3.0 mm
306 71 13 mm 3.0 mm
Complete rolls

R+M Nr.
306 560 50 9 mm 50 m 3.0 mm
306 710 50 13 mm 50 m 3.0 mm

Symbols nozzle wall thickness nominal diameter
