Page 72 - RM_2022

High pressure equipment 03

Suttner chemical injectors
ST-60 ST-62 Metering valves Repair kits

47 1
55
2
DN 6
49
Injector without metering valve. Injector without metering valve. Adjustable Valve for Suttner Chemical check valve.
Max. 250 bar / 60 °C bypass allows big water flow rates without reduc- injector. Hose tail 6 mm
tion of the water pressure. Max. 250 bar / 60 °C Hose tail 6 mm
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
200 060 600 3/8" M 3/8" F 1.8 mm 200 062 500 3/8" F NPT 3/8" F NPT 1.6 mm 050 000 370 1 200 060 725
200 060 610 3/8" M 3/8" F 2.1 mm 200 061 500 2
200 060 620 3/8" M 3/8" F 2.4 mm

Suttner foam injectors

ST-60.1 with coupling ST-60.1 ST-60.1 with quick screw coupling

47

DN 6

Coupling ST-45-250 : plug ST-45-250. Injector Injector without metering valve. M22 F : M22 M. Injector with metering valve,
with metering valve, suction hose 1,000 mm and Max. 250 bar / 60 °C suction hose 1,000 mm and suction filter ST-31.
suction filter ST-31. Max. 250 bar / 60 °C R+M Nr. Max. 250 bar / 60 °C
R+M Nr. 200 060 700 3/8" M 3/8" F 1.6 mm R+M Nr.
200 060 750 1.6 mm 200 060 710 3/8" M 3/8" F 1.8 mm 200 060 760 1.6 mm
Metering valves Repair kits
Valve for Suttner Chemical check valve.
1 injector. Hose tail 6 mm Hose tail 6 mm

R+M Nr. R+M Nr.
2 The suitable foam lances are
050 000 370 1 200 060 725
200 061 500 2 presented on pages 335, 336.

Accumulator

64 84 100

92
113 158
Volume 0.07 liter. Max. 80 °C Volume 0.21 liter. Max. 85 °C Volume 0.35 liter. Max. 85 °C
R+M Nr. R+M Nr. R+M Nr.
189 307 0 M14 M 15 - 200 bar 189 321 0 M16 M 25 - 220 bar 189 211 0 * 3/8" F 40 - 210 bar
189 321 2 3/8" M 25 - 220 bar
* Accumulator must be filled with nitrogen

Symbols inlet outlet nozzle type nominal diameter pressure thread

71
