High pressure equipment 03

Suttner flow switches
Spare parts flow switches

limited stock

Floater ST-5 with hole REED switch ST-5 & ST-505
R+M Nr. cable
Functional principle of a flow switch
R+M Nr. 200 005 435 1.200 mm
200 005 520 200 005 438 3.500 mm Without waterflow With waterflow
ST-6 flow switches
3/8" M : 3/8" M. Horizontal or
vertical mount. Cable 1,200 mm.
Contact 1 A - 250 V.
1.8 l closed. 1.4 l open.
Max. 310 bar / 30 l/min / 80 °C

The floater is in resting position. The floater is in working position.
R+M Nr.
The contact is open. The contact is closed by the mag-
200 006 700
netic floater.

REED switch ST-6. Floater ST-6
Cable 1,200 mm
R+M Nr. R+M Nr.
200 006 436 200 006 490
ST-7 flow switches
The ST-7 is a newly developed version of the flow switch having a
completely new operating principle.
In this new development a robust and industrial micro switch is inserted
instead of the usually supersensitive REED-contacts with low switching
capacity.
This micro switch makes it possible to realize a significantly higher electrical
output though having a longer working life.
The electrical and water-hydraulic components of the flow switch are
completely separated.
The construction of the flow switch allows mounting the electrical parts
independent of the hydraulic components within the series production
process.
When fitting together chassis and switch box both parts of the flow switch
3/8" F. Protection class IP65. Cable 1,200 mm. 10 A. 250 V. Inrush current are connected again.
20 A (NC) and 15 A (NO). Max. 350 bar / 45 l/min / 80 °C Due to the mature engineering low switching points are realized in spite of
maximum water quantities.
R+M Nr. switch-on points
The pressure drop within the flow switch is only 1.5 bar at 30 l/min.
200 007 500 4.0 l/min 4.9 l closed. 3.5 l open
200 007 510 1.5 l/min 1.5 l closed. 0.8 l open
Spare parts flow switches ST-7
Repair-Kit floater ST-7 Repair-Kit switch ST-7.
Cable 1,200 mm

R+M Nr. R+M Nr.
200 007 497 4 l/min 200 007 498
200 007 499 1.5 l/min

Symbols length flow type thread temperature
