High pressure equipment 03

High pressure solenoid valves closed in off-position
Danfoss VDHT Danfoss solenoid coil

96
22
102 94.8 2 x ø 6.5
21.5
39
17.4 10 35
27.5
55
Stainless steel. Viton. Pressure range 0 - 160 bar. Without coil. Max. 90 °C 24 V / DC / 16 W
R+M Nr. R+M Nr.
837 180 094 1/2" 60 l/min 837 018 791 4
837 180 092 3/8" 30 l/min
Rapa SV 04
R apa SV 04 AK Connector

A
1/4" F. NW 1.5 mm. Solenoid valve with 1/4" F. NW 1.2 mm. Solenoid valve without R+M Nr.
connector. Pressure range 0 - 130 bar. Max. 90 °C connector. Pressure range 0 - 180 bar. Max. 90 °C 833 50
R+M Nr. R+M Nr.
832 01 24 V = 833 10 48 mm 109 mm 24 V =
832 00 24 V ~ 50 Hz
832 10 230 V ~ 50 Hz
AK

A
1/4" F. NW 1.2 mm. Solenoid valve with connec-
tor. Pressure range 0 - 180 bar. Max. 90 °C
R+M Nr.
833 15 48 mm 109 mm 24 V ~ 50 Hz
833 00 48 mm 109 mm 230 V ~ 50 Hz

Symbols thread height length voltage flow type inlet outlet diameter
