04 Electrical equipment

Motor protection switches Time hour meter
Type OKN cutout
45
22
44,5
45
21,0
90,0 77,5 50,0 45

53,0
Meter with clip
K F
R+M Nr.
Housing for type OKN 915 102 4 24 V ~
R+M Nr. working range R+M Nr. 915 122 0 230 V ~
901 516 10.0 - 16.0 A 901 540 plastic 915 140 0 400 V ~
901 522 16.0 - 22.0 A
901 527 22.0 - 27.0 A Remote thermometers
Type WIMEX new new With contact probe and adjustable knob

80 77
99,0 64,0
52,0
44
R+M Nr. working range Housing for type WIMEX, IP55 60,0 8,0
901 710 6.3 - 10.0 A R+M Nr. 1/2" M. Contact 5 A - 250 V (AC1). Indication of
901 716 10.0 - 16.0 A 901 730 plastic temperature 0 - 120 °C
901 720 16.0 - 20.0 A R+M Nr. working range tube length
901 725 20.0 - 25.0 A 910 20 0 - 80 °C 1,000 mm

Remote thermostats

Emerson 1536 Probe with screw Emerson 8654

38,0 35,0
46,0
6,0 6,0 6,0
50,0 65,0 44,5 51,5 48,0 56,0
51,0 8,0 28,0 48,0 8,0 28,0 51,0 8,0 28,0
F K W
M14 x 1 M. Contact 16 A - 380 V (AC1) 3/8" M. Contact 16 A - 380 V (AC1) 3/8" M. Contact 16 A - 380 V (AC1)
R+M Nr. working range tube length R+M Nr. working range tube length R+M Nr. working range tube length
910 16 0 - 160 °C 1,550 mm 910 12 30 - 150 °C 1,520 mm 910 15 30 - 150 °C 1,550 mm
910 13 0 - 152 °C 920 mm
Probe pocket PS1
Ø26
3/8”
new
82
107
3/8” 3/8”
25
1/2”
Ø28
47
Brass. Max. 280 bar / 160° C
R+M Nr.
178 290 260 35
