| The Professionals

2801 NEW 3001 Sale while stocks last

Two Schuko-Sockets, Automatic shutdown at low oil level. Field of application: average electric tools, hammer drills, angular grinders,
Big fuel tank for long operating times with optical fuel indicator. lawn mowers, light supply, etc.
Compact design. Operating time with one tank filling up to 9 hours. Auto-
matic low oil level shut down. Two Schuko-sockets. Disengageable starting
amplifier.

450 mm 390 mm

570 mm 465 mm 520 mm 410 mm

2801 E–A/SHBA 2801 E–A/HHBA 3001 E–AA/HHBA
Order-No.: 986216 Order-No.: 986218 Order-No.: 986211
GTIN: 4038469231983 GTIN: 4038469235943 GTIN: 4038469962115

Engine Briggs & Stratton Honda Alternator Asynchronous
Alternator Aynchronous Aynchronous El. capacity: 1~ cos φ 1,0 3000 VA
El. capacity: 1~ cos φ 1,0 2200 VA 2200 VA Voltage 1~ 230 V
Voltage 1~ 230 V 230 V Max. sum. current 1~ 13 A
Current 1~ 10,6 A 10,6 A Current 1~ (Schuko) 13 A
Frequency 50 Hz 50 Hz (with 20% voltage drop) 17 A 1~
Safety class alternator IP 54 IP 54 Frequency 50 Hz
Engine type B&S Series XR950 Honda GP200 Safety class alternator IP 54
Number of cylinders 1 1 Engine type Honda GX 200 Low Noise
Rotation-speed (3000 1/min) 3000 U min -1 3000 U min -1 Number of cylinders 1
Fuel type Gasoline Gasoline Rotation-speed (3000 1/min) 3000 U min -1
Engine oil capacity 0,6 l 0,6 l Fuel type Gasoline
Engine power (3000 1/min) 4 kW 3,3 kW Engine oil capacity 0,6 l
Cooling engine/alternator Air / Air Air / Air Engine power 3,3 kW
Tank capacity 15 l 15 l Cooling engine/alternator Air / Air
Operating time: full load/half load 12,5 / 15 h 12,5 / 15 h Tank capacity 8 l
Weight 42 kg 42 kg Operating time: full load/half load 5 / 7 h
Dimensions L x W x H 570 x 465 x 450 mm 570 x 465 x 450 mm Weight 48 kg

Noise power level L WA 96 dB(A) 96 dB(A) Dimensions L x W x H 520 x 410 x 390 mm
Noise pressure (10m) 68 dB(A) 68 dB(A) Noise power level L WA 96 dB(A)
Noise pressure (10m) 68 dB(A)

Accessory (optional) Order-No. Accessory (optional) Order-No.
Exhaust hose 904872 3) Exhaust hose 904872 3)
Adapter for exhaust hose 015658 Adapter for exhaust hose 904768
Lifting set 911643 Fuel cap with lockable venting 900601
Chassis (pre-finished) 988548 Isometer 988641 6)9)
Protection switch FI (earthing set incl.) 904370 6)8)
Waterproof sockets 903051
6)
GW 308 988521
Chassis (pre-finished) 988548
Lifting set 911643
6)
Voltmeter 908300
Amperemeter 908350 6)
Earthing set 908250
Option Economic mode 988901

For further accessories, please see the price list

16 Technical information is based on average values and may vary in individual cases. For this reason, the technical 1) n/a in cunjunction with BLC/GE803 3) only with adapter for exhaust hose 5) n/a in conjunction with handles or chassis
information is not binding. Images are non-binding. For misprints we accept no liability. 2) n/a in conjunction with UBC 4) only with E-start
