| The Professionals

4401 PS NEW 5401 Sale while stocks last

Silent design with large airfilter and large exhaust muffler for noise reduction. Silent design with large airfilter and large exhaust muffler for noise reduction.
Switchbox operation opposite to the exhaust-pipe. Safe battery Switchbox operation opposite to the exhaust-pipe. Safe battery
implementation into the switch box. Automatic shut down if low oil level is implementation into the switch box. Automatic shut down if low oil level is
detected. Fuel gauge. Disengageable starting amplifier. detected. Fuel gauge. Disengageable starting amplifier. Operating time with
3x Schuko-socket IP67, 1x 12V DC socket one tank filling up to 14,5 hours.
One CEE 16A-3ph. socket, one CEE 16A-1ph. socket, one Schuko-socket.

530 mm 530 mm

736 mm 580 mm 740 mm 500 mm
Illustration shows optional accessories

4401 E–AA/HHBA PS 4401 E–AA/HEBA PS 5401 ED–AA/HHBA 5401 ED–AA/HEBA
Order-No.: 986386 Order-No.: 986387 Order-No.: 988474 Order-No.: 988476
GTIN: 4038469232195 GTIN: 4038469232201 GTIN: 4038469984742 GTIN: 4038469984766

Alternator Asynchronous Alternator Asynchronous
El. capacity: 1~ cos φ 1,0 3700 VA El. capacity: 3~ cos φ 1,0 4100 VA
Voltage 1~ 230 V El. capacity: 1~ cos φ 1,0 3800 VA
Max. sum. current 1~ 16 A Voltage 3~ 400 V
Current 1~ (Schuko) 16 A Voltage 1~ 230 V
Frequency 50 Hz Current 3~ 5,9 A
Safety class alternator IP 54 Max. sum. current 1~ 16,5 A
Engine type Honda GX270 RT2 Current 1~ (CEE) 16 A
Number of cylinders 1 Current 1~ (Schuko) 16 A
Rotation-speed (3000 1/min) 3000 U min -1 Max. starting current cos φ 0,6 12,5 A 3~
Fuel type Gasoline (with 20% voltage drop) 22 A 1~
Engine oil capacity 1,1 l Frequency 50 Hz
Engine power 4,6 kW Safety class alternator IP 54
Cooling engine/alternator Air / Air Engine type Honda GX 270 Super Silent
Tank capacity 19 l Number of cylinders 1
Operating time: full load/half load 17 / 21 h Rotation-speed (3000 1/min) 3000 U min -1
Weight 96 /104 kg with battery Fuel type Gasoline

Dimensions L x W x H 736 x 580 x 530 mm Engine oil capacity 1,1 l
Noise power level L WA 95 dB(A) Engine power 5,4 kW
Cooling engine/alternator Air / Air
Tank capacity 20 l
Operating time: full load/half load 8 / 14,5 h
Weight 89 / 97,5 kg with battery
Dimensions L x W x H 740 x 500 x 530 mm
Noise power level L WA 96 dB(A)
Nach TA-Lärm Noise pressure (10m) 68 dB(A)
Accessory (optional) Order-No. Accessory (optional) Order-No.
Exhaust hose 9048723) Exhaust hose 904872 3)
Adapter for exhaust hose 904880 Adapter for exhaust hose 904880
Operating control ComAp Nano 988830 Remote starting 908246 1)2)4)6)
Remote start (in combination with ComAp) 988831 Protection switch FI (earthing set incl.) 904390 1)6)8)
Option Economic mode 988832 2) Waterproof sockets 903052 6)
Insulation control 988833 GW 308 988523 1)6)
Insulation control with shutdown 988834 Chassis (pre-finished) 988548
Automatic Choke 988835 Standard starting battery 020316 (E-Start)
ATS control panel nano external 1ph. 988837 Emergency power change-over MNU 3ph. (ext.) 988331
Chassis (pre-finished) 988745 ATS control panel nano external (E-Start) 904766 4)6)
Lifting set 911643 Add. fuel tank 50 l (assembly kit required) 923995 5)6)7)
Earthing set 908250 Add. fuel tank 100 l (assembly kit required) 923998 5)6)7)
Add. fuel tank 80 l 988839 Add. fuel tank 150 l (assembly kit required) 923963 5)6)7)
T-valve for external fueling 988828 Assembly kit for additional fuel tank 923994 6)
Option Economic mode mode (hand start/ e-start) 988904/ 988905
more accessories on the accessories list

18 Technical details are based on average values and can vary a spread of ± 10%. 1) n/a in cunjunction with BLC/GE803 3) only with adapter for exhaust hose 5) n/a in conjunction with handles or chassis
Illustrations are non-binding. We are not liable for errata. 2) n/a in conjunction with UBC 4) only with E-start
