| The Professionals

13001 7801 (230V) DIESEL

Field of application: larger electric tools, compressors, pumps, safety, gas Field of application: average electric tools, angular grinders, hammer drills,
welding units, larger construction-site machines, el. welding. Automatic shut lawn mower, garden shredders, el. welding.
down if low oil level is detected. Extremely long lifetime. Disengageable starting amplifier.
Full single phase of 6000W via one 32A-socket. Full single phase of 4500 W via one 32A-socket.
One CEE-32A-3ph. socket, one CEE 32A-1ph. socket, One CEE-32A-1ph.-socket, two Schuko-sockets.
one Schuko-socket. T-valve for external fueling included

650 mm 530 mm

790 mm 550 mm 740 mm 500 mm

13001 ED–S/SEBA 7801 E–AA/ZEDA
Order-No.: 986656 Order-No.: 986471
GTIN: 4038469966564 GTIN: 4038469100326

Alternator Synchronous Alternator Asynchronous
El. capacity: 3~ cos φ 0,8 13000 VA El. capacity: 1~ cos φ 1,0 6400 VA
El. capacity: 1~ cos φ 0,8 6000 VA Voltage 1~ 230 V
Voltage 3~ 400 V Max. sum. current 1~ 28 A
Voltage 1~ 230 V Current 1~ (CEE) 28 A
Current 3~ 18,6 A Current 1~ (Schuko) 16 A
Max. sum. current 1~ 42 A Max. starting current cos φ 0,6
Current 1~ (CEE) 26 A (with 20% voltage drop) 56 A 1~
Current 1~ (Schuko) 16 A Frequency 50 Hz
Max. starting current cos φ 0,6 30 A 3~ Safety class alternator IP 54
(with 20% voltage drop) 55 A 1~ Engine type Hatz 1B50
Frequency 50 Hz Number of cylinders 1
Safety class alternator IP 54 Rotation-speed (3000 1/min) 3000 U min -1
Engine type B&S 23 HP Fuel type Diesel
Number of cylinders 2 Engine oil capacity 1,5 l
Rotation-speed (3000 1/min) 3000 U min -1 Engine power 7,6 kW
Fuel type Gasoline Cooling engine/alternator Air / Air
Engine oil capacity 1,7 l Tank capacity 5 l
Engine power 13,2 kW Operating time: full load/half load 2,2 / 3,4 h
Cooling engine/alternator Air / Air Weight 132 kg w/o battery
Tank capacity 10 l Dimensions L x W x H 740 x 500 x 530 mm
Operating time: full load/half load 2 / 3,5 h Noise power level L WA 104 dB(A)
Weight 138 kg with battery Noise pressure (10m) 76 dB(A)
Dimensions L x W x H 790 x 550 x 650 mm
Noise power level L WA 98 dB(A)
Noise pressure (10m) 70 dB(A)
Accessory (optional) Order-No. Accessory (optional) Order-No.
Exhaust hose 904872 3) Exhaust hose 904872 3)
Remote starting 908257 1)2)4)6) Adapter for exhaust hose 904762
Can fueling set 988530 Remote starting 908252 1)2)4)6)
Protection switch FI (earthing set incl.) 904400 1)6)8) Protection switch FI (earthing set incl.) 904746 1)6)8)
GW 308 988479 1)6) Waterproof sockets 903052 6)
Chassis (pre-finished) 988548 GW 308 988534 1)6)
Standard starting battery (mit Add. fuel tank 10 l) 020316 (E-Start) Chassis (pre-finished) 988548
Standard starting battery (ohne Add. fuel tank 10 l) 901067 (E-Start) Standard starting battery 901067 (E-Start)
Emergency power change-over MNU 3ph. (ext.) 988332 Emergency power change-over MNU 3ph. (ext.) 988331
ATS control panel nano external 3ph. (E-Start) 904778 4)6) ATS control panel nano external 1ph. (E-Start) On request 4)6)
Add. fuel tank 10 l 900563 6 Add. fuel tank 50 l (assembly kit required) 924149 5)6)7)
Add. fuel tank 50 l (standard tank dispenses) 923945 5)6)7) Add. fuel tank 100 l (assembly kit required) 924150 5)6)7)
Add. fuel tank 100 l (standard tank dispenses) 923949 5)6)7) Add. fuel tank 150 l (assembly kit required) 924151 5)6)7)
Add. fuel tank 150 l (standard tank dispenses) 924145 5)6)7) Assembly kit for additional fuel tank 923996 6)
Fuel extraction device 915230
Option Economic mode 988915 more accessories on the accessories list
more accessories on the accessories list
22 Technical details are based on average values and can vary a spread of ± 10%. 1) n/a in cunjunction with BLC/GE803 3) only with adapter for exhaust hose 5) n/a in conjunction with handles or chassis
Illustrations are non-binding. We are not liable for errata. 2) n/a in conjunction with UBC 4) only with E-start
