07 High pressure hoses & hose fittings

High pressure hoses with wrapped cover
Quick screw coupling : QSC Quick screw coupling : QSC swivel QSC : plug swivel
M22 : M22 M22 : M22 M21 : M21 M22 : M22 M22 : M22 M21 : M21 M22 : 11 M22 : 11
swivel
swivel
swivel
swivel
swivel

suitable
suitable
suitable
suitable
suitable
suitable
system 2000
K system 2000 K W system 2000 K system 2000 K W system 2000 K system 2000 K
Hoses with single wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 6 250 bar 150 °C 10 m 330 100 310 330 120 310 330 101 310 330 121 310 330 111 310
15 m 330 100 315 330 120 315 330 101 315 330 121 315 330 111 315
20 m 330 100 320 330 120 320 330 101 320 330 121 320 330 111 320
1SN 8 210 bar 150 °C 10 m 340 100 310 340 100 410 340 120 310 340 101 310 340 101 410 340 121 310 340 111 410
15 m 340 100 315 340 100 415 340 120 315 340 101 315 340 101 415 340 121 315 340 111 415
20 m 340 100 320 340 100 420 340 120 320 340 101 320 340 101 420 340 121 320 340 111 420
1SN 8 315 bar 150 °C 10 m 343 100 310 343 100 410 343 120 310 343 101 310 343 101 410 343 121 310 343 111 410
15 m 343 100 315 343 100 415 343 120 315 343 101 315 343 101 415 343 121 315 343 111 415
20 m 343 100 320 343 100 420 343 120 320 343 101 320 343 101 420 343 121 320 343 111 420
1SN 10 210 bar 150 °C 10 m 350 100 310 350 100 410 350 120 310 350 101 310 350 101 410 350 121 310
15 m 350 100 315 350 100 415 350 120 315 350 101 315 350 101 415 350 121 315
20 m 350 100 320 350 100 420 350 120 320 350 101 320 350 101 420 350 121 320
Hoses with double wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 6 400 bar 150 °C 10 m 335 100 310 335 120 310 335 101 310 335 121 310 335 111 310
15 m 335 100 315 335 120 315 335 101 315 335 121 315 335 111 315
20 m 335 100 320 335 120 320 335 101 320 335 121 320 335 111 320
2SC 8 400 bar 150 °C 10 m 345 100 310 345 100 410 345 120 310 345 101 310 345 101 410 345 121 310 345 111 410
15 m 345 100 315 345 100 415 345 120 315 345 101 315 345 101 415 345 121 315 345 111 415
20 m 345 100 320 345 100 420 345 120 320 345 101 320 345 101 420 345 121 320 345 111 420
2SC 10 400 bar 150 °C 10 m 355 100 310 355 100 410 355 120 310 355 101 310 355 101 410 355 121 310
15 m 355 100 315 355 100 415 355 120 315 355 101 315 355 101 415 355 121 315
20 m 355 100 320 355 100 420 355 120 320 355 101 320 355 101 420 355 121 320
Hoses with single wire braid and wrapped thick cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1ST 8 210 bar 150 °C 10 m 340 200 310 340 200 410 340 220 310 340 201 310 340 201 410 340 221 310 340 211 410
15 m 340 200 315 340 200 415 340 220 315 340 201 315 340 201 415 340 221 315 340 211 415
20 m 340 200 320 340 200 420 340 220 320 340 201 320 340 201 420 340 221 320 340 211 420
1ST 10 210 bar 150 °C 10 m 350 200 310 350 200 410 350 220 310 350 201 310 350 201 410 350 221 310
15 m 350 200 315 350 200 415 350 220 315 350 201 315 350 201 415 350 221 315
20 m 350 200 320 350 200 420 350 220 320 350 201 320 350 201 420 350 221 320

All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel

Our hose assemblies are durably marked on the crimp in accordance with EN 853 / EN 856 / EN 855.
Symbols diameter nominal diameter pressure temperature length type
