High pressure hoses & hose fittings 07

High pressure hoses with smooth cover
Female thread (DKOL) Female thread (DKR) Male thread (AGR)
M16 : M16 M18 : M18 M22 : M22 1/4" : 1/4" 3/8" : 3/8" 1/2" : 1/2" 1/4" : 1/4" 3/8" : 3/8" 1/2" : 1/2"
10L : 10L 12L : 12L 15L : 15L

Hoses with single wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
Flexy 6 300 bar 100 °C 10 m 390 074 210 390 076 210 390 052 210 390 054 210 390 042 210 390 044 210
15 m 390 074 215 390 076 215 390 052 215 390 054 215 390 042 215 390 044 215
20 m 390 074 220 390 076 220 390 052 220 390 054 220 390 042 220 390 044 220
Hoses with single wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 8 250 bar 150 °C 10 m 340 674 310 340 676 310 340 652 310 340 654 310 340 642 310 340 644 310
15 m 340 674 315 340 676 315 340 652 315 340 654 315 340 642 315 340 644 315
20 m 340 674 320 340 676 320 340 652 320 340 654 320 340 642 320 340 644 320
1SN 10 210 bar 150 °C 10 m 350 676 310 350 668 310 350 654 310 350 656 310 350 642 310 350 644 310 350 646 310
15 m 350 676 315 350 668 315 350 654 315 350 656 315 350 642 315 350 644 315 350 646 315
20 m 350 676 320 350 668 320 350 654 320 350 656 320 350 642 320 350 644 320 350 646 320
Hoses with double wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SN 8 400 bar 150 °C 10 m 345 674 310 345 676 310 345 652 310 345 654 310 345 642 310 345 644 310
15 m 345 674 315 345 676 315 345 652 315 345 654 315 345 642 315 345 644 315
20 m 345 674 320 345 676 320 345 652 320 345 654 320 345 642 320 345 644 320
2SN 10 400 bar 150 °C 10 m 355 676 310 355 668 310 355 654 310 355 656 310 355 642 310 355 644 310 355 646 310
15 m 355 676 315 355 668 315 355 654 315 355 656 315 355 642 315 355 644 315 355 646 315
20 m 355 676 320 355 668 320 355 654 320 355 656 320 355 642 320 355 644 320 355 646 320

All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel
