High pressure hoses & hose fittings 07

High pressure hoses with wrapped cover and smooth cover
Quick screw couplings Plug & crimp st. steel QSC : QSC swivel QSC : plug swivel *
M22 : M22 M21 : M21 M22 : M22 M21 : M21 M22 : M22 M21 : M21 M22 : 10 M22 : 11
swivel
swivel
swivel

suitable
suitable system 2000
suitable
suitable
suitable
system 2000
system 2000
system 2000
system 2000
K W K W K WK K
Hoses with single wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 6 250 bar 150 °C 10 m 331 100 610 331 120 610 331 100 610 7 331 120 610 7 331 101 610 331 121 610 331 110 610 331 111 610
15 m 331 100 615 331 120 615 331 100 615 7 331 120 615 7 331 101 615 331 121 615 331 110 615 331 111 615
20 m 331 100 620 331 120 620 331 100 620 7 331 120 620 7 331 101 620 331 121 620 331 110 620 331 111 620
1SN 8 210 bar 150 °C 10 m 341 100 610 341 120 610 341 100 610 7 341 120 610 7 341 101 610 341 121 610 341 110 610 341 111 610
15 m 341 100 615 341 120 615 341 100 615 7 341 120 615 7 341 101 615 341 121 615 341 110 615 341 111 615
20 m 341 100 620 341 120 620 341 100 620 7 341 120 620 7 341 101 620 341 121 620 341 110 620 341 111 620
1SN 10 210 bar 150 °C 10 m 351 100 610 351 120 610 351 100 610 7 351 120 610 7 351 101 610 351 121 610
15 m 351 100 615 351 120 615 351 100 615 7 351 120 615 7 351 101 615 351 121 615
20 m 351 100 620 351 120 620 351 100 620 7 351 120 620 7 351 101 620 351 121 620
Hoses with single wire braid and wrapped thick cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1ST 8 210 bar 150 °C 10 m 341 200 610 341 220 610 341 200 610 7 341 220 610 7 341 201 610 341 221 610 341 210 610 341 211 610
15 m 341 200 615 341 220 615 341 200 615 7 341 220 615 7 341 201 615 341 221 615 341 210 615 341 211 615
20 m 341 200 620 341 220 620 341 200 620 7 341 220 620 7 341 201 620 341 221 620 341 210 620 341 211 620
1ST 10 210 bar 150 °C 10 m 351 200 610 351 220 610 351 200 610 7 351 220 610 7 351 201 610 351 221 610
15 m 351 200 615 351 220 615 351 200 615 7 351 220 615 7 351 201 615 351 221 615
20 m 351 200 620 351 220 620 351 200 620 7 351 220 620 7 351 201 620 351 221 620
Hoses with double wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 8 400 bar 150 °C 10 m 346 100 610 346 120 610 346 100 610 7 346 120 610 7 346 101 610 346 121 610 346 110 610 346 111 610
15 m 346 100 615 346 120 615 346 100 615 7 346 120 615 7 346 101 615 346 121 615 346 110 615 346 111 615
20 m 346 100 620 346 120 620 346 100 620 7 346 120 620 7 346 101 620 346 121 620 346 110 620 346 111 620
2SC 10 400 bar 150 °C 10 m 356 100 610 356 120 610 356 100 610 7 356 120 610 7 356 101 610 356 121 610
15 m 356 100 615 356 120 615 356 100 615 7 356 120 615 7 356 101 615 356 121 615
20 m 356 100 620 356 120 620 356 100 620 7 356 120 620 7 356 101 620 356 121 620
Hoses with single wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 10 210 bar 150 °C 10 m 351 600 610 351 620 610 351 600 610 7 351 620 610 7 351 601 610 351 621 610
15 m 351 600 615 351 620 615 351 600 615 7 351 620 615 7 351 601 615 351 621 615
20 m 351 600 620 351 620 620 351 600 620 7 351 620 620 7 351 601 620 351 621 620
Hoses with double wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SN 8 400 bar 150 °C 10 m 346 600 610 346 620 610 346 600 610 7 346 620 610 7 346 601 610 346 621 610 346 610 610 346 611 610
15 m 346 600 615 346 620 615 346 600 615 7 346 620 615 7 346 601 615 346 621 615 346 610 615 346 611 615
20 m 346 600 620 346 620 620 346 600 620 7 346 620 620 7 346 601 620 346 621 620 346 610 620 346 611 620
2SN 10 400 bar 150 °C 10 m 356 600 610 356 620 610 356 600 610 7 356 620 610 7 356 601 610 356 621 610
15 m 356 600 615 356 620 615 356 600 615 7 356 620 615 7 356 601 615 356 621 615
20 m 356 600 620 356 620 620 356 600 620 7 356 620 620 7 356 601 620 356 621 620
* not to be used for patented Kärcher guns.

All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel
