High pressure hoses & hose fittings 07

High pressure hoses with wrapped cover
Female thread (DKOL) Female thread (DKR) Male thread (AGR)
M16 : M16 M18 : M18 3/8" : 3/8" 1/2" : 1/2" 3/8" : 3/8" 1/2" : 1/2"
10L : 10L 12L: 12L

Hoses with single wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 6 250 bar 150 °C 10 m 332 174 510 332 176 510 332 154 510 332 144 510
15 m 332 174 515 332 176 515 332 154 515 332 144 515
20 m 332 174 520 332 176 520 332 154 520 332 144 520
1SN 8 210 bar 150 °C 10 m 342 174 510 342 176 510 342 154 510 342 144 510
15 m 342 174 515 342 176 515 342 154 515 342 144 515
20 m 342 174 520 342 176 520 342 154 520 342 144 520
1SN 10 210 bar 150 °C 10 m 352 176 510 352 154 510 352 156 510 352 144 510 352 146 510
15 m 352 176 515 352 154 515 352 156 515 352 144 515 352 146 515
20 m 352 176 520 352 154 520 352 156 520 352 144 520 352 146 520
Hoses with double wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 8 400 bar 150 °C 10 m 347 174 510 347 176 510 347 154 510 347 144 510
15 m 347 174 515 347 176 515 347 154 515 347 144 515
20 m 347 174 520 347 176 520 347 154 520 347 144 520
2SC 10 400 bar 150 °C 10 m 357 176 510 357 154 510 357 156 510 357 144 510 357 146 510
15 m 357 176 515 357 154 515 357 156 515 357 144 515 357 146 515
20 m 357 176 520 357 154 520 357 156 520 357 144 520 357 146 520
High pressure hoses with smooth cover

Female thread (DKOL) Female thread (DKR) Male thread (AGR)
M16 : M16 M18 : M18 3/8" : 3/8" 1/2" : 1/2" 3/8" : 3/8" 1/2" : 1/2"
10L : 10L 12L: 12L

Hoses with double wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SN 8 400 bar 150 °C 10 m 347 674 510 347 676 510 347 654 510 347 644 510
15 m 347 674 515 347 676 515 347 654 515 347 644 515
20 m 347 674 520 347 676 520 347 654 520 347 644 520
2SN 10 400 bar 150 °C 10 m 357 676 510 357 654 510 357 656 510 357 644 510 357 646 510
15 m 357 676 515 357 654 515 357 656 515 357 644 515 357 646 515
20 m 357 676 520 357 654 520 357 656 520 357 644 520 357 646 520

Our hose assemblies are durably marked on the crimp in accordance with EN 853 / EN 856 / EN 855.

All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel
