High pressure hoses & hose fittings 07
High pressure hoses for hose reels
M22 : M22 M22 : M22 M22 : M14 M22 : M22 KW : KW
Brass swivel Brass swivel swivel coupling
7,9
Kr Kr Kr Kr Kr Kr
Hoses with single wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
1SN 6 250 bar 150 °C 15 m 330 113 381 5 330 107 815
1SN 8 210 bar 150 °C 15 m 340 113 381 5
1SN 8 250 bar 150 °C 15 m 340 601 815 1
20 m R+M Nr. 340 601 820 1
Hose with single wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
flexy 6 300 bar 100 °C 10 m 390 007 810
15 m 390 013 381 390 007 815
Hoses with double wire braid and smooth cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SN 8 400 bar 150 °C 15 m 345 601 815 1 345 616 815
20 m 345 601 820 1 345 616 820
30 m 345 616 830
Hoses with double wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 10 400 bar 150 °C 20 m 355 115 332 0
Our hose assemblies are durably marked on the crimp in accordance with EN 853 / EN 856 / EN 855.
All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel
