High pressure hoses & hose fittings 07

High pressure hoses for self-service washing bays
Hoses with single wire braid and wrapped cover. 1SN. Nominal diameter 6. Max. 210 bar /150 °C
1/4" : 1/4" 3/8" : 3/8" 1/4" : 1/4" M14 : M14 M14 : M14

Female thread (DKR) Female thread (DKR) Female thread (DKR) Female thread (DKOL) VA Female thread (DKOL)
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
331 152 803 5 3.5 m 331 154 803 5 3.5 m 331 152 603 5 3.5 m 331 172 803 59 3.5 m 331 172 803 5 3.5 m
331 152 604 4.0 m 331 172 804 4.0 m
331 152 804 2 4.2 m 331 154 804 2 4.2 m 331 152 604 2 4.2 m 331 172 804 29 4.2 m
331 172 804 79 4.7 m
331 152 805 5.0 m 331 154 805 5.0 m 331 172 805 5.0 m
331 152 605 5 5.5 m
M22 : 10 swivel

Further high pressure hoses suitable for
K K self-service washing bays are available on request.
QSC - swivel disc plug QSC - swivel disc plug

R+M Nr. R+M Nr.
330 117 303 5 3.5 m 331 117 303 5 3.5 m
330 117 304 4.0 m 331 117 304 4.0 m
330 117 304 2 4.2 m 331 117 304 2 4.2 m
331 117 305 5.0 m
330 117 310 10.0 m 331 117 310 10.0 m
