07 High pressure hoses & hose fittings

Galvanator - food hose
Interior synthetic rubber. Resistant to usual detergents. Very temperature-resistant. Double zinc-plated steel wire braid. Surface special synthetic rubber.
Resistant to poultry fats. Non Marking (soot free). Field of application: poultry farms, slaughterhouses, fishing, bakeries etc. Not suitable for swimming
baths, standard and industrial cleaning applications.
Quick screw couplings QSC: QSC Female thread (DKR) M (AGR)
The advantages of the zinc-plated steel
braids become obvious when effecting M22 : M22 M22 : M22 1/2" : 1/2" 3/8" : 3/8"
swivel
a salt water test. The Galvanator has
been soaked in a 5 % salt water solution
at 45 °C for 48 hours.

suitable
suitable
suitable system 2000 system 2000 system 2000
suitable
system 2000
Nipple & Stainless steel Zinc-plated Nipple & Stainless steel Zinc-plated Stainless steel
crimp VA steel crimp VA steel
Hoses with double wire braid made out of zinc-plated steel and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr. R+M Nr.
Galvanator 10 350 bar 121 °C 10 m 359 100 410 7 359 100 410 9 359 100 410 359 101 410 7 359 156 410 9 359 156 410 359 144 410 9
15 m 359 100 415 7 359 100 415 9 359 100 415 359 101 415 7 359 156 415 9 359 156 415 359 144 415 9
20 m 359 100 420 7 359 100 420 9 359 100 420 359 101 420 7 359 156 420 9 359 156 420 359 144 420 9
25 m 359 100 425 7 359 100 425 9 359 100 425 359 101 425 7 359 156 425 9 359 156 425 359 144 425 9
30 m 359 100 430 7 359 100 430 9 359 100 430 359 101 430 7 359 156 430 9 359 156 430 359 144 430 9
35 m 359 100 435 7 359 100 435 9 359 100 435 359 101 435 7 359 156 435 9 359 156 435 359 144 435 9
40 m 359 100 440 7 359 100 440 9 359 100 440 359 101 440 7 359 156 440 9 359 156 440 359 144 440 9
Food hoses
» Interior synthetic rubber. Very Quick screw couplings
temperature-resistant. Resistant to usual
detergents. M22 : M22 M22 : M22
swivel
» Surface special synthetic rubber. Non
marking (soot free). Resistant to animal
fats.
» Field of application: slaughterhouses,
fishing, bakeries etc. Not suitable for
swimming baths, poultry fat, standard and
industrial cleaning applications.
Other lengths or
suitable
suitable
suitable
connections
system 2000
system 2000
system 2000
are available on request.
Nipple & Stainless steel Zinc-pl. steel Nipple &
crimp VA crimp VA
Hoses with double wire braid and wrapped cover
R+M Nr. R+M Nr. R+M Nr. R+M Nr.
2SC 8 400 bar 150 °C 10 m 349 100 410 7 349 100 410 9 349 100 410 349 101 121 07
15 m 349 100 415 7 349 100 415 9 349 100 415 349 101 121 57
20 m 349 100 420 7 349 100 420 9 349 100 420 349 101 122 07
2SC 10 400 bar 150 °C 10 m 381 100 410 7 381 100 410 9 381 100 410
15 m 381 100 415 7 381 100 415 9 381 100 415
20 m 381 100 420 7 381 100 420 9 381 100 420

All fittings are made out of zinc-plated steel. The hoses are also available with stainless steel fittings.
Please be so kind as to state the following on your order: R+M Nr. plus number:
7 = plug and crimp stainless steel 8 = plug stainless steel 9 = plug, crimp and connection stainless steel

Symbols nominal diameter pressure temperature length type burst pressure packing unit
