High pressure hoses & hose fittings 07
High pressure hoses
Quick screw couplings
M22 : M22 M22 : M22 M22 : M22
plug VA
swivel
suitable
suitable
suitable
Hoses with single wire braid and wrapped cover system 2000 system 2000 system 2000
R+M Nr. R+M Nr. R+M Nr.
1SN 8 315 bar 150 °C 10 m 344 100 710 344 100 710 8 344 101 710
15 m 344 100 715 344 100 715 8 344 101 715
20 m 344 100 720 344 100 720 8 344 101 720
Symbols nominal diameter pressure temperature length type
